A01 DRUM SUB AS 3617030010 D-M300 1
A02 LIFTER WASH 361A401900 D-M300, PP 3
A03 SPIDER AS 361A301610 D-M300 1
A04 SPECIAL BOLT 3616063000 STS430 M6*21 SI-LOCK 3
DRAIN MOTOR AS 3919601110
SAMCO, NEW 220~240V 50/60HZ 5/6RPM PV ASM
1
A05 DRAIN MOTOR 3919601100 SAMCO, 220V 5/6RPM,SSM-16HR 1
A06 DRAIN HOUSING 36196TC010 D-M300, FRPP, FILTER TYPE 1
A07 CAP FILTER DRAIN 36196TC050 D-M300, FRPP, FILTER TYPE 1
A08
PACKING CAP FILTER DRAIN
36196TC060 D-M300, NBR 40 1
A09 HOSE AIR TRAP 3613276800 D-M300, EPDM 1
A10 CLAMP HOSE 3611204700 ID27 2
A11 AIR TRAP 361A500300 D-M300, PP 1
A12 HOSE AIR 3613276900 D-M300, EPDM ID=4 OD=8, L=455 1
A13 SENSOR PRESSURE 3614825320 DL-DW12-H AIR INLET 270 HOOK TYPE 1
A14 EMI FILTER 3611913000 DFC-2712D ,250V 12A, 1
A15 FIXTURE HEATER 3612007310 SUS 304 0.7T 440X45 1 1
A16 HEATER WASH 3612804000
220V.140MM.1400W.TERMINAL 1R8A721.IRCA FUSE 2EA
1
A17 INVERTER MOTOR 36189L8000 DWD200BL, DC 310 V, 125 W, CLASS F 1
A18 SPECIAL BOLT 3616067000 TRS S/W P/W HEX:5*16 SUS304 4
A19 SPECIAL SCREW 7S422X4081 TT3 TRS 4X8 SE MFZN 2
A20 BRACKET EARTH 3610603500 SBHG1 T1.2 1
A21
VALVE CHECK AS(1/4")
3615418450 D-M300,1/4",POM 1
A22 Y DIVIDER 3612512900 D-M300, ATWD0404 1/4' DMT 1
A23 HOSE INLET 3613270980 DFE04 LLDPE ID=4,OD=6 0.575
A24 VALVE INLET 3615401000 AC 220V/60HZ, SV-11CWB-01,1WAY 2
A25 TUB REAR SUB AS 3618831620
D-M300. TUB REAR+BEARING HOUSING
1
BEARING INNER 3616305900 D-M300,6203ZZ,ID=17,OD=40 1
WATER SEAL 361A600900 D-M300,NBR ID=25,OD=50 1
DRAIN HOUSING 36196TC000 FRPP 1
BOND 2224050106 218W 0.005
A26 HOSE VENT AS 3613217940 D-M300 HOSE VENT AS 1
A27 PULLEY 3618434300 D-M300, ALDC 1
A28 SPECIAL BOLT AS 3616063110 M8X27 S/W P/W SI-LOCK HEX:13 1
A29 BELT V 3616591600 D-M300, 4PJ-1020 1
A30 HARNESS AS 361279C000 D-M301 ,MINI WASH,FULL OPTION 1
361279C010 D-M300 ,MINI WASH,NON HEATER 1
361279C020
D-M301 ,MINI WASH,FULL OPTION,NON EMI
1
361279C030
D-M300, MINI WASH,NON HEATER,NON EMI
1
A31 MAIN PCB AS 361NPCB942
MINI,V.E,220,J,COLD+HEATER-O,NO-EMI(PERU,ARAB)
1
361NPCB943
MINI,V.E,220,J,COLD+HEATER-O,EMI(RUSSIA)
1
361NPCB946
MINI,V.E,220,J,COLD+HEATER-X,NO-EMI(PERU,ARAB)
1
361NPCB947
MINI,V.E,220,J,COLD+HEATER-O,EMI(CHINA)
1
A32 REACTOR 3615800500 RT-028 L=3.6MH(0A),L=5.2MH(1A) 1 OPTION
DRAIN
MOTOR
ASSMBLY
No. PART NAME PART CODE DESCRIPTION Q’TY REMARK
TUB REAR
ASSMBLY
To Next Page
