90
◆DSA-095L
No PART CODE PART NAME Q'TY SPEC REMARK
1 3114302010 CONTROL PCB ASS’Y1
2 3108914100 TERMINAL BLOCK 1 JXO-CH-3P
3 3106900300 CAPACITOR SH.M.B 1 1.0µF 400VAC
4 3104896300 SENSOR ID ASS’Y 1 PTM-KD43C-D2
5 3101301700 POWER CORD ASS’Y 1 250V 15A
6 3102797610 HARNESS 1 I/D COMP
7 3102797910 HARNESS 1 I/D EARTH
8 3102704000 HARNESS 1 POWER
9 3102704500 HARNESS 1 LED PCB
10 3101200400 CLAMP CORD 1 DA-5N
11 3108003910 STEPPING MOTOR 1 24BYJ48-1
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
To Next Page
