108
◆PART LIST (INDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
1 3100400600 BODY 1
2 3108007510 MOTOR IDU 1 IC-9430DWKF7A
3 3101500400 CUSHION MOTOR 2 CR I.D30 (R/W45)
4 3106400200 BEARING PLASTIC ASSY 1 O.D37.0*I.D6.0
5 3100076400 FAN CROSS FLOW ASSY 1 OD 100*L864
6 7485401012 SET SCREW 1 6S-4*10-E MFZN(BLACK)
7 3103003800 HOLDER MOTOR L/B 1
8 3103003900 HOLDER MOTOR R 1
9 3103004000 HOLDER BEARING 1 ABS T2.5
10 311009AC01 EVAP. ASSY 1 FP1.4 2R5C
11 3102501400 GUIDE EVAP. 1
12 3108101400 PAN DRAIN 1
13 3106502700 BLADE VERTICAL M 3
14 3107600500 FLAP UP 1
15 3107600600 FLAP DOWN 1
16 3107801700 LINK FLAP 1
17 3100702000 BUSHING 2
18 3103200800 HOSE DRAIN ASSY 1
19 3108007600 MOTOR STEPPING 1 GSP-24RW-062
20 3104301700 LED PCB ASSY 1
21 3110079310 CONTROL BOX ASSY 1
21-1 3100510700 BOX CONTROL 1
3114302200 DSB-183AH/PH, 240AH-R/PH-R
21-2
3114305600
CONTROL PCB ASSY 1
DSB-240A-R/P-R
3114303700 DSA-183AH-R/PH-R
3114303800 DSA-183A-R/P-R SN-DBW-6P
21-3 3108914400 TERMINAL BOLCK 1
21-4 3101300440 POWER CORD 1 SJT 3X14 AWG105
21-5 3101200400 CLAMP CORD 1 DA-5N
21-6 3104897010 SENSOR ID ASSY 1 AC-04, PTM-KD43C-D2
21-7 5EPV050120 TRANSFORMER 1 DWA-220B
21-8 3106902400 CAPACITOR MOLD 1 2.0UF 400V
21-9 3113701800 VOLTAGE GENERATOR 1 NAHG-006 AC220V 50/60Hz 5.6kV
21-10 2150013200 AL FOIL EMI 1 AL100P(W100XL100)
21-11 3112716600 HARNESS AC SIGNAL 1 UL1015 WHITE(L6000) AH-R/A-R ONLY
22 3100400700 BODY TOP 1
23 3102201400 FRAME GRILLE 1
24 3104512400 PLATE LED 1 PC SHEET T0.2
25 3104510200 PLATE SWITCH 1 PC SHEET T0.2
26 3103401400 KNOB SWITCH 1
27 3113700500 DUST COLLECTOR 1 NAC-002
28 3100094300 FILTER CARBON 1
29 3101406800 COVER T/BLOCK 1
30 3102201500 FILTER FRAME 2
31 3102403550 GRILLE INSERT 1 ABS
32 3101406900 COVER LED 1
33 3104512600 PLATE INSERT GRILLE 1 PET T0.1
34 3104511800 PLATE MOUNTING 1
35 3111405200 COVER O2 HOSE 1 ABS AH-R/A-R ONLY
36 3113202210 HOSE 1 OD6.0 x L600 AH-R/A-R ONLY
37 3108701400 COUPLING 1 ø6-ø6 CONNECT AH-R/A-R ONLY
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
