◆PART LIST(OUTDOOR UNIT)
No PART CODE PART NAME Q'TY SPEC REMARK
1
3100014720
PAN BASE ASSY 1 SECC T1.2
(B)-071/093AH
3100014700 (B)-123AH/PH
2 3106000900 COMP. BOLT 3 M8 x L46.5
3 3102100800 FOOT 1 SECC T1.2
4 3108104AE0 COMP. GROMMET 3 EPDM
3117104470 RBB075A011 (B)-071AH
5 3117104480 COMPRESSOR ASSY 1 RBB100A011 (B)-093AH
3117104370 RCB135U001 (B)-123AH/PH
6 7400208411 COMP. WASHER 3 M8.4 x 22 x T1.6 DW
7 7392801211 COMP. NUT 3 M8xP1.25 MFZN DW
3110046200 1 ROW
8 3110064900 CONDENSER ASSY 1 L465xW208.5xH508 1 ROW
3100014100 2 ROW
9
3114434400
PIPE COND IN 1
(B)-071/093AH
3104410700 (B)-123AH/PH
10
3114433700
PIPE COND OUT 1
(B)-071/093AH
3104412800 (B)-123AH/PH
11 3100602200 BRACKET SERVICE 1 SECC T1.2
12 3115401900 SERVICE VALVE 1 3/8" (GAS)
13
3105400802
SERVICE VALVE 1
1/4" (LIQUID) (B)-071AH
3105401101 1/4" (LIQUID) (B)-093/123AH/PH
14 7347602011 BOLT HEX 4 M6x20 MFZN
15
3110048000
PIPE REVERSING ASSY 1
(B)-071/093AH
3100038800 (B)-123AH/PH
3110048300 (B)-071AH
16 3110048410 PIPE FILTER ASSY 1 (B)-093AH
3110083101 (B)-123AH/PH
3114424300 PIPE CAPILLARY 1 OD3.2xID1.2xL700 (B)-071AH
3114424410
PIPE CAPILLARY COOL 1
OD3.2xID1.4xL700 (B)-093AH
17 3114442601 OD3.2xID1.78xL600 (B)-123AH/PH
3114442510
PIPE CAPILLARY HEAT 1
OD3.2xID1.8xL600 (B)-093AH
3114442500 OD3.2xID1.78xL800 (B)-123AH/PH
18 3102501100 GUIDE SUPPORT 1 SECC T1.2
19 3102402600 GRILLE CONDENSER 1 P.E. 660x525.5xT3.5
20 3100601903 BRACKET MOTOR 1 SBHG1 T1.2
3118009010 YDK-40-4B (B)-123AH/PH
21 3118003900 MOTOR ODU 1 YDK-35-6B
(B)-071/093AH
3118001200 A9530BD010
22 3101801000 FAN PROPELLER 1
ABS+G.F20% (BLACK)
23 7400208411 WASHER PLAIN 1 PW-2-8 MFZN
24 7392800011 NUT LOCK 1 M8 x P1.25 MFZN
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
