119
◆DSB-071AH
No PART CODE PART NAME Q'TY SPEC REMARK
1 3114314200 ASSY CONTROL PCB 1
2 3108003900 MOTOR STEPPING 1 MP24GA , GSP-24SW-061
3 3108914300 TERMINAL BLOCK 1 JXO-CH-5P
4 3112704450 HARNESS AC SIGNAL 1 1 UL1015 #20 x 6000 WHT
5 3104896300 ASSY SENSOR ID 1 PTM-KD43C-D2
6 3101300100 ASSY POWER CORD 1 250V 16A H05VV-F 3 x 1.0mm
2
7 3102797610 HARNESS I/D COMP 1 UL1015 #18 BLU
8 3102797150 HARNESS 4WAY VALVE 1 UL1015 #20 BLK
9 3102704400 HARNESS O/D MOTOR 1 UL1015 #20 WHT
10 3102797910 HARNESS I/D EARTH 1 UL1015 #16 GRN/YEL
11 3102704000 HARNESS POWER 1 UL105 2 x #16 BRN,BLU
12 3102702200 HARNESS TH3 1 UL2464 2x #24 x 6000
13 3102704500 HARNESS LED PCB 1 UL1007 8x #24 WHT
14 3101204600 CLAMP CORD 1 DA-4N
15 3106900300 CAPACITOR IDU 1 1.0µF 400VAC
16 3100084000 CONTROL BOX 1 PP+ GF20%
✔ Caution
: In this Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service Information Center (http://svc.dwe.co.kr).
To Next Page
