No. PARTS NAME CODE SPECIFICATIONS Q’TY REMARK
E01 DUCT B UPPER 361A202400 ALCOSTA 1
E02 SCREW TAPPING 7122401411 T2S TRS 4X14 MFZN 8
E03 SCREW TAPPING 7112401208 T1 TRS 4X12 SUS 1
E04 HEATER DRY 3612801400
230V 2.1KW 25.19OHM 6.1W/SQ INCOLOY800 1R1A034002
1
E05 PACKING THERMOSTAT 3614009900 SILICON, DWD-100DR 1
E05 SWITCH THERMOSTAT 3619046500 ON120°C OFF150°C 230V 15A VDE 1
E06 DUCT B LOWER 361A202500 ALDC C-LU1011 1
E07 BUSHING UPPER 3610703800 POM C-LU1011 4
E08 BUSHING LOWER 3610703900 POM C-LU1011 4
E09 GASKET SEAL A 3612325700 EPDM FOAM, D=5, L=1293 1
E10 PACKING RUBBER 3614009800 SILICON, DWD-100DR 1
E10 THERMISTOR DRY 361AAAAD00
C-LD/LU,L=200,R40=26.065K,R90=4.4278K
1
E11 NUT HEX 3616032100 M6*1.0P,CCW 1
E12 FAN AS 3611886400 GFPP30% , C-LU1011 1
E13 COVER DUCT 3611431400 GFPP30% C-LU1011 1
E14 RING O 3614603400 DWD-100DR,NBR,ID=7.6,OD=13.6 1
E15 UNIT FAN MOTOR 36189M2Q00 24V DC 14W 1
To Next Page
