17
TROUBLE SHOOTING
assy panel
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
P01 KNOB 3613403800 160C, ABS 4.0000 160C
P02 PANEL B 3614240000 HIPS 1.0000
P03 TIMER WASH 3619911170 S-DT15NT-M 1.0000
P04 LEVER CONTROL 3613701400 POM 2.0000 500M
P05 LINK VALVE 3617804600 PP BAND 0.7T, L2=796 1.0000 YELLOW
P06 TIMER SPIN 3619900900
AC 125V/6A,250V/3A S-6200A
1.0000
P07 BRACKET CONTROL 3610607300 HIPS 1.0000
P08 SWITCH DRAIN 3619043700 VP531A-2H, 250VAC/15A 1.0000
P09 SPRAY HOSE 3613225400 PE-LD 1.0000
assy accessory
NO. PART NAME PART CORD SPECIFICATION Q’TY REMARKS
A01 SAFETY COVER 3611418900 PE-LD+EVA 1.0000
In this Service Manual, some parts can be changed for improving, their performance without notice in the parts list. So, if you need the
latest parts information, please refer to PPL(Parts Price List) in Service information Center(http://svc.dwe.co.kr)
