ENGINE CONTROLS 1F–53
DAEWOO M-150 BL2
Data Link Connector Diagnosis
Step Action Value(s) Yes No
1
Perform an Euro On-Board Diagnostic (EOBD)
System Check.
Was the check performed?
–
Go to Step 2
Go to “Euro
On-Board
Diagnostic
System Check.
2
With a test light connected to the ground, probe the
Data Link Connector (DLC) battery feed terminal 16.
Is the test light on?
–
Go to Step 4 Go to Step 3
3
Repair an open or short to ground in the DLC battery
feed circuit .
Is the repair complete?
–
Go to Step 4
–
4
With a test light connected to the battery, probe the
Data Link Connector (DLC) ground terminal 4 and 5.
Is the test light on?
–
Go to Step 6 Go to Step 5
5
Repair an open circuit .
Is the repair complete?
–
Go to Step 6
–
6
1. Turn the ignition OFF.
2. Connect a scan tool to the Data Link Connector
(DLC).
3. Turn the ignition ON.
Does the scan tool power up?
–
Go to Step 8 Go to Step 7
7
Check for damages in the terminal of DLC and scan
tool, and repair as needed.
Is the repair complete?
–
Go to Step 8
–
8
Using a scan tool, request engine data of Engine
Control Module (ECM).
Does the scan tool display any data?
–
Go to Step 12 Go to Step 9
9
Install the scan tool on another vehicle and check for
proper operation.
Does the scan tool work properly on a different
vehicle.
–
Go to Step 11 Go to Step 10
10
The scan tool is malfunctioning.
Refer to the scan tool’s manual for repair.
Is the repair complete?
–
Go to Step 12
–
11
Repair communication circuit between ECM and
DLC.
Is the repair complete?
–
Go to Step 12
–
12
1. Using a scan tool, clear the Diagnostic Trouble
Codes(DTCs).
2. Attempt to start the engine.
Does the engine and continue to run?
–
Go to Step 13 Go to Step 1
13
1. Allow the engine to idle until normal operation
temperature reached.
2. Check if any DTCs are set?
Are any DTCs displayed that have not been
diagnosed?
–
Go to applicable
DTC table
System OK
