Change the Lamp Ass’y.
Start
Repair the F-door switch.
Check the F-door
switch Connection.
Y
N
N
Y
Change of F Lights Change of F Door Switch
* Remove 2 screws
of light cover.
* Unscrew 2 points.
* Pull out connector
from F-Lamp Ass’y.
* Insert a flat tip screw
driver Into a gap of door
switch to pull forward.
* Disconnect the housing
and change the switch
for a new one.
①
②
③
①
②
8-2-3. Disconnection / breaking of Freezer Lights Ass’y
Freezer Lamp Ass’y
Is brocken?
Connection of F door
switch is OK ?
※ Follow the reverse order
of disassembling after
changing the switch.
Power of F-Lamp
Is OK ? (DC12V)
Check the power connection?
(From Main PCB to F-Lamp)
N
Y
④
* Check the power of
F-Lamp connector
(DC 12V)
To Next Page
