Daikin 2MXS-N Series User Manual

Specifications EDUS121503A
38 Multi-Split Type Air Conditioners 2/3/4MXS-N Series
15+15 Duct Wall — — 14.75 14.75 — — 29.50 9.60 ~ 31.30 2710 720 ~ 2960 13.3 3.5 ~ 14.5 98
15+15 Duct Duct — — 14.00 14.00 — — 28.00 9.20 ~ 29.00 2820 870 ~ 2940 13.8 4.3 ~ 14.4 98
15+18 Wall Wall — — 15.23 18.27 — — 33.50 10.00 ~ 35.80 2990 560 ~ 3410 14.7 2.7 ~ 16.7 98
15+18 Wall Duct — — 14.32 17.18 — — 31.50 9.60 ~ 33.40 3020 710 ~ 3350 14.8 3.5 ~ 16.4 98
15+18 Duct Wall — — 14.32 17.18 — — 31.50 9.60 ~ 33.40 3030 720 ~ 3300 14.9 3.5 ~ 16.2 98
15+18 Duct Duct — — 13.41 16.09 — — 29.50 9.20 ~ 31.00 3050 860 ~ 3310 15.0 4.2 ~ 16.2 98
15+24 Wall Wall — — 14.88 21.12 — — 36.00 10.20 ~ 38.00 3430 550 ~ 3430 16.8 2.7 ~ 16.8 98
15+24 Wall Duct — — 13.93 19.77 — — 33.70 9.80 ~ 35.70 3290 690 ~ 3430 16.1 3.4 ~ 16.8 98
15+24 Duct Wall — — 13.93 19.77 — — 33.70 9.90 ~ 35.70 3260 710 ~ 3390 16.0 3.5 ~ 16.6 98
15+24 Duct Duct — — 12.93 18.37 — — 31.30 9.40 ~ 33.30 3250 850 ~ 3390 15.9 4.2 ~ 16.6 98
18+18 Wall Wall — — 18.00 18.00 — — 36.00 10.00 ~ 38.00 3480 560 ~ 3550 17.1 2.7 ~ 17.4 98
18+18 Duct Wall — — 16.75 16.75 — — 33.50 9.60 ~ 35.50 3350 710 ~ 3420 16.4 3.5 ~ 16.8 98
18+18 Duct Duct — — 15.50 15.50 — — 31.00 9.20 ~ 33.00 3300 850 ~ 3440 16.2 4.2 ~ 16.9 98
18+24 Wall Wall — — 16.49 19.51 — — 36.00 10.20 ~ 38.00 3430 540 ~ 3430 16.8 2.6 ~ 16.8 98
18+24 Wall Duct — — 15.53 18.37 — — 33.90 9.80 ~ 35.80 3290 690 ~ 3430 16.1 3.4 ~ 16.8 98
18+24 Duct Wall — — 15.53 18.37 — — 33.90 9.90 ~ 35.80 3310 700 ~ 3450 16.2 3.4 ~ 16.9 98
18+24 Duct Duct — — 14.52 17.18 — — 31.70 9.40 ~ 33.50 3310 840 ~ 3440 16.2 4.1 ~ 16.9 98
24+24 Wall Wall — — 18.00 18.00 — — 36.00 10.30 ~ 38.00 3310 520 ~ 3450 16.2 2.6 ~ 16.9 98
24+24 Duct Wall — — 17.10 17.10 — — 34.20 10.00 ~ 36.00 3250 680 ~ 3390 15.9 3.3 ~ 16.6 98
24+24 Duct Duct — — 16.15 16.15 — — 32.30 9.50 ~ 34.00 3320 820 ~ 3450 16.3 4.0 ~ 16.9 98
07+07+07 Wall Wall Wall — 7.60 7.60 7.60 — 22.80 9.20 ~ 25.20 1800 580 ~ 2070 8.8 2.8 ~ 10.2 98
07+07+09 Wall Wall Wall — 7.66 7.66 9.58 — 24.90 9.30 ~ 27.60 2020 580 ~ 2420 9.9 2.8 ~ 11.9 98
07+07+09 Wall Wall Duct — 7.57 7.57 9.46 — 24.60 9.20 ~ 26.40 2070 630 ~ 2290 10.2 3.1 ~ 11.2 98
07+07+12 Wall Wall Wall — 7.39 7.39 12.92 — 27.70 9.40 ~ 30.70 2360 580 ~ 2860 11.6 2.8 ~ 14.0 98
07+07+12 Wall Wall Duct — 7.23 7.23 12.64 — 27.10 9.20 ~ 29.20 2400 630 ~ 2710 11.8 3.1 ~ 13.3 98
07+07+15 Wall Wall Wall — 6.71 6.71 16.78 — 30.20 10.00 ~ 32.90 2470 560 ~ 2920 12.1 2.7 ~ 14.3 98
07+07+15 Wall Wall Duct — 6.51 6.51 16.28 — 29.30 9.60 ~ 31.40 2650 720 ~ 2960 13.0 3.5 ~ 14.5 98
07+07+18 Wall Wall Wall — 6.54 6.54 19.62 — 32.70 10.00 ~ 35.10 2860 560 ~ 3330 14.0 2.7 ~ 16.3 98
07+07+18 Wall Wall Duct — 6.30 6.30 18.90 — 31.50 9.60 ~ 33.50 3020 710 ~ 3350 14.8 3.5 ~ 16.4 98
07+07+24 Wall Wall Wall — 6.49 6.49 23.02 — 36.00 10.20 ~ 38.00 3430 550 ~ 3430 16.8 2.7 ~ 16.8 98
07+07+24 Wall Wall Duct — 6.20 6.20 22.00 — 34.40 9.80 ~ 36.40 3430 690 ~ 3430 16.8 3.4 ~ 16.8 98
07+09+09 Wall Wall Wall — 7.66 9.57 9.57 — 26.80 9.40 ~ 30.00 2240 580 ~ 2730 11.0 2.8 ~ 13.4 98
07+09+09 Wall Wall Duct — 7.54 9.43 9.43 — 26.40 9.30 ~ 28.60 2290 630 ~ 2590 11.2 3.1 ~ 12.7 98
07+09+09 Wall Duct Duct — 7.40 9.25 9.25 — 25.90 9.20 ~ 27.10 2280 690 ~ 2460 11.2 3.4 ~ 12.1 98
07+09+12 Wall Wall Wall — 7.33 9.16 12.81 — 29.30 9.40 ~ 32.20 2610 580 ~ 3130 12.8 2.8 ~ 15.4 98
07+09+12 Wall Wall Duct — 7.13 8.91 12.46 — 28.50 9.30 ~ 30.70 2590 630 ~ 2970 12.7 3.1 ~ 14.6 98
07+09+12 Wall Duct Wall — 7.13 8.91 12.46 — 28.50 9.30 ~ 30.70 2590 630 ~ 2910 12.7 3.1 ~ 14.3 98
07+09+12 Wall Duct Duct — 6.95 8.69 12.16 — 27.80 9.20 ~ 29.20 2570 690 ~ 2820 12.6 3.4 ~ 13.8 98
07+09+15 Wall Wall Wall — 6.69 8.37 16.74 — 31.80 10.00 ~ 34.40 2730 560 ~ 3200 13.4 2.7 ~ 15.7 98
07+09+15 Wall Wall Duct — 6.46 8.08 16.16 — 30.70 9.70 ~ 32.80 2840 720 ~ 3230 13.9 3.5 ~ 15.8 98
07+09+15 Wall Duct Wall — 6.46 8.08 16.16 — 30.70 10.00 ~ 32.80 2650 620 ~ 2970 13.0 3.0 ~ 14.6 98
07+09+15 Wall Duct Duct — 6.23 7.79 15.58 — 29.60 9.60 ~ 31.30 2760 780 ~ 3080 13.5 3.8 ~ 15.1 98
07+09+18 Wall Wall Wall — 6.53 8.17 19.60 — 34.30 10.00 ~ 36.50 3130 560 ~ 3410 15.4 2.7 ~ 16.7 98
07+09+18 Wall Wall Duct — 6.27 7.83 18.80 — 32.90 9.70 ~ 34.90 3220 710 ~ 3430 15.8 3.5 ~ 16.8 98
07+09+18 Wall Duct Wall — 6.27 7.83 18.80 — 32.90 10.00 ~ 34.90 2970 620 ~ 3310 14.6 3.0 ~ 16.2 98
07+09+18 Wall Duct Duct — 5.98 7.48 17.94 — 31.40 9.60 ~ 33.30 3070 770 ~ 3400 15.1 3.8 ~ 16.7 98
07+09+24 Wall Wall Wall — 6.21 7.76 22.03 — 36.00 10.20 ~ 38.00 3430 540 ~ 3430 16.8 2.6 ~ 16.8 98
07+09+24 Wall Wall Duct — 5.95 7.44 21.11 — 34.50 9.80 ~ 36.40 3430 690 ~ 3430 16.8 3.4 ~ 16.8 98
07+09+24 Wall Duct Wall — 5.95 7.44 21.12 — 34.50 10.10 ~ 36.40 3200 600 ~ 3410 15.7 2.9 ~ 16.7 98
07+09+24 Wall Duct Duct — 5.67 7.09 20.14 — 32.90 9.70 ~ 34.90 3200 750 ~ 3410 15.7 3.7 ~ 16.7 98
07+12+12 Wall Wall Wall — 7.07 12.37 12.37 — 31.80 9.50 ~ 34.40 3000 580 ~ 3410 14.7 2.8 ~ 16.7 98
07+12+12 Wall Wall Duct — 6.83 11.94 11.94 — 30.70 9.30 ~ 32.80 2910 630 ~ 3310 14.3 3.1 ~ 16.2 98
07+12+12 Wall Duct Duct — 6.58 11.51 11.51 — 29.60 9.20 ~ 31.30 2880 690 ~ 3140 14.1 3.4 ~ 15.4 98
07+12+15 Wall Wall Wall — 6.53 11.43 16.33 — 34.30 10.00 ~ 36.50 3130 560 ~ 3410 15.4 2.7 ~ 16.7 98
07+12+15 Wall Wall Duct — 6.27 10.97 15.67 — 32.90 9.70 ~ 34.90 3240 720 ~ 3440 15.9 3.5 ~ 16.9 98
07+12+15 Wall Duct Wall — 6.27 10.97 15.67 — 32.90 10.00 ~ 34.90 2970 620 ~ 3380 14.6 3.0 ~ 16.6 98
07+12+15 Wall Duct Duct — 5.98 10.47 14.95 — 31.40 9.60 ~ 33.30 3080 780 ~ 3410 15.1 3.8 ~ 16.7 98
07+12+18 Wall Wall Wall — 6.26 10.96 18.78 — 36.00 10.10 ~ 38.00 3490 560 ~ 3560 17.1 2.7 ~ 17.5 98
07+12+18 Wall Wall Duct — 5.98 10.47 17.94 — 34.40 9.70 ~ 36.40 3500 710 ~ 3570 17.2 3.5 ~ 17.5 98
07+12+18 Wall Duct Wall — 5.98 10.47 17.96 — 34.40 10.00 ~ 36.40 3240 620 ~ 3380 15.9 3.0 ~ 16.6 98
07+12+18 Wall Duct Duct — 5.69 9.95 17.07 — 32.70 9.60 ~ 34.70 3270 770 ~ 3400 16.0 3.8 ~ 16.7 98
Combination
of
indoor unit
Type of indoor unit
Capacity of each indoor unit
Each capacity (kBtu/h) Total capacity (kBtu/h) Total input (W) Total current (A)
Power
factor (%)
A room B room C room D room A room B room C room D room Rating (min ~ max) Rating (min ~ max) Rating (min ~ max) Rating

Daikin 2MXS-N Series Specifications

General

Brand	Daikin
Model	2MXS-N Series
Category	Heat Pump
Language	English
