Daikin 4MXL-T Series User Manual

SiUS121827E Piping Diagrams
Part 8 Appendix 281
FVXS09/12NVJU FVXS15/18NVJU
FDMQ09/12/15/18/24RVJU FFQ09/12/15/18Q2VJU
INDOOR UNIT
MUFFLER ASSY HEAT EXCHANGER
1/4 CuT
9/32 CuT
1/4 CuT
1/4 CuT
1/4 CuT
M
FAN MOTORTURBO FAN
1/4 CuT
3/8 CuT
FIELD PIPING
(1/4 CuT)
FIELD PIPING
(3/8 CuT)
THERMISTOR
REFRIGERANT FLOW
COOLING
HEATING
4D091794
INDOOR UNIT
MUFFLER ASSY HEAT EXCHANGER
1/4 CuT
9/32 CuT
1/4 CuT
1/4 CuT
1/4 CuT
1/4 CuT
M
1/4 CuT
FAN MOTORTURBO FAN
1/4 CuT
3/8 CuT
REFRIGERANT FLOW
COOLING
HEATING
FIELD PIPING
(
1/4 CuT
)
FIELD PIPING
(
1/2 CuT
)
THERMISTOR
ON HEAT EXCH.
4D091795A
4D112974
4D106033
HEAT EXCHANGER
FAN
REFRIGERANT FLOW
COOLING
HEATING
FFQ09Q2VJU 1/4 (6.4)
3/8 (9.5)
1/2 (12.7)
FFQ12Q2VJU
FFQ15Q2VJU
FFQ18Q2VJU
MODEL A B
LIQUID PIPE
CONNECTION PORT
φA
GAS PIPE
CONNECTION PORT
φB
