4. Move the backplate out of the way and make holes where
indicated in the previous step. The mounting holes can
accommodate a #6 pan-head screw. It is recommended to
use the included fasteners to ensure proper tting of the
front housing.
5. Use the included drywall plugs (or other suitable anchors) to
ensure the thermostat can be mounted securely to the wall.
6. Fasten the backplate and optional trim plate to the wall
using the screws provided (or other suitable screws).
The solid color indicates mounting holes
AUXRCD+D-
AUX
R
11
