CAUTION
When removing or attaching the front panel, use a robust and stable stool and watch your steps carefully.•
When removing or attaching the front panel, support the panel securely with hand to prevent it from falling.•
After cleaning, make sure that the front panel is securely fi xed.•
Remove the front panel.1.
Open the front panel.•
Open the front panel at least 90 degrees.•
Release the front panel locks on each side, and •
disconnect the front panel shaft.
Front panel shaft
3) Slide
Front panel locks
Open at least 90 degrees.
4) Pull
3) Slide
2) Slide
4) Pull
1) Pull
Disconnect the front panel shaft on the other •
side in the same manner.
Clean the front panel.2.
Wipe it with a soft cloth soaked in water.•
Only neutral detergent may be used.•
Attach the front panel.3.
Align the front panel shaft on the left and right of •
the front panel with the slots, then push them all
the way in.
Front panel shaft
Slot
Front panel locks
1) Slide
2) Push
Close the front panel slowly.•
Removing the front panel
