10 User Guide RS8KH202 © Danfoss 2019-03 AK-PC 572
Start/stop
Main switch
Main switch
Start and stop regulating here.
The configuration settings will require that regulating is stopped.
If you try to enter a configuration setting when regulating has started, the controller will
ask if regulating should be stopped.
When all settings have been made and the main switch is set to “ON”, the controller will
enable the display of the various measurements. Regulation will start. (One external main
switch must be “ON” before regulating starts.)
On / Off
Extern Main swich
Status on External main switch
It is possible to connect an external switch which can be used to start and stop regulating.
Both the internal and external main switch must be ON before regulating starts.
If the external cutout is omitted, the dedicated input must be shorted.
Plant type
Select Plant type Plant settings:
The following must be regulated:
• Booster + HP
• MT + HP
Fac: None
Mains frequency Frequency
Set the net frequency
50 Hz / 60 Hz
Fac: 50 Hz
Suction MT
Control status MT Regulation status
Control status Read the status of the functions in the control circuit here
Reference The total regulation reference can be read here
ToMT temperature The measured PoMT pressure converted to temperature can be read here
PoMT Pressure The measured pressure for the PoMT pressure transmitter can be read here
Requested capacity Here the preferred connected capacity can be read as a % of total capacity
Running capacity Here the connected capacity can be read as a % of total capacity
No. of running comp. The number of compressors in operation can be read here
MC PoMT offset The size of a reference displacement on PoMT required from the system unit
(suction pressure optimisation function) can be read here
SdMT discharge
temp.
The measured discharge temperature can be read here
SsMT Suction gas
temp.
The measured suction gas temperature can be read here
Superheat MT The actual superheat can be read here
Day / Night status The status of the day/night function can be read here
Load shed The status of the load shed function can be read here
HP Safety switch The status of the security circuit can be read here
Injection ON MT The status of the injection ON signal sent to the evaporator controllers can be read here
Liq. inj. suction line
The status of hte liquid injection in the suction line can be read here
MC Load Shedding The status of the load shed signal received from the system device can be read here
MC Night Setback The status of the night increase signal received from the system device can be read here
Control settings Regulation settings
Control mode Regulation type
The regulation is normally set to “Auto”, but it can be changed to “Off” or “Manual”.
MAN / OFF / AUTO
Fac: AUTO
Manual capacity When setting to “Manual”, a forced capacity setting can subsequently be entered in %.
Min: 0 %
Max: 100%
Setpoint Enter the set point for the regulation (regulation reference = set point + different offsets) here
An offset can originate from a night increase signal or from an override function on the
system device.
Min: -55°C
Max: 20°C
Fab: -10°C
PI control selection Set how quickly the PI regulation must react here: 1 = slowly, 10 = very quickly.
Min: 1
Max: 10
Fab: 5
