Danfoss TS710 User Manual

User Guide TS710 Single Channel Heating Timer
2
Danfoss Heating
VUSUG102 05/2019
1 Functional Overview
Symbols
Function
description
Symbols
Function
description
Mon–Sun
Current set day Time and date setup
Current on/o
period
Heating active
Schedule setup
Heating channel 1
current mode
AM
PM
Current set time /
parameter setup
Away mode
2 Buttons
Symbols Function description
Schedule setup
(menu access*)
OK
Conrm settings
(date and time setup*)
Menu navigation / day
selection
< >
Time and setting changes
/ channel mode selection
CH
Channel selection
(holiday mode selection*)
* To access additional feature press and hold button for 3 secs
3 Set Date & Time
• Press and hold OK button for 3 seconds; Yr ashes. Press < or > buttons to adjust year
• Press OK button again; Mth ashes. Press < or > buttons to adjust month
• Press OK button again; Day ashes. Press < or > buttons to adjust day of the month
• Press OK button again; Hr ashes. Press < or > buttons to adjust hour
• Press OK button again; Min ashes. Press < or > buttons to adjust minute
• Press OK button to exit, automatic exit after 20 seconds if no buttons pressed

Danfoss TS710 Specifications

General

Mounting	DIN rail
Number of channels	1
Protection class	IP20
Switching capacity	16A
Ambient temperature range	-10°C to +55°C
