Parameter
no.
Description Display
text
Unit Updating
interval
515 Reference % (REFERENCE) % 80 msec.
516 Reference Unit (REFERENCE [UNIT]) Hz, Nm or rpm 80 msec.
517 Feedback (FEEDBACK) To be selected via
par. 416
80 msec.
518 Frequency (FREQUENCY) Hz 80 msec.
519 Frequency x Scaling (FREQUENCY X SCALE) - 80 msec.
520 Current (MOTOR CURRENT) Amp x 100 80 msec.
521 Torque (TORQUE) % 80 msec.
522 Power, kW (POWER (KW) kW 80 msec.
523 Power, HP (POWER (HP) HP (US) 80 msec.
524 Motor voltage (MOTOR VOLTAGE) V 80 msec.
525 DC link voltage (DC LNK VOLTAGE) V 80 msec.
526 Motor temp. (MOTOR THERMAL) % 80 msec.
527 VLT temp. (VLT THERMAL) % 80 msec.
528 Digital input (DIGITAL INPUT) Binary code 2 msec.
529 Terminal 53, analogue in-
put
(ANALOG INPUT 53) V 20 msec.
530 Terminal 54, analogue in-
put
(ANALOG INPUT 54) V 20 msec.
531 Terminal 60, analogue in-
put
(ANALOG INPUT 60) mA 20 msec.
532 Pulse reference (PULSE REFERENCE) Hz 20 msec.
533 External reference % (EXT. REFERENCE) 20 msec.
534 Status word (STATUS WORD [HEX]) Hex code 20 msec.
535 Brake power/2 min. (BR. ENERGY/2 MIN) kW
536 Brake power/sec. (BRAKE ENERGY/S) kW
537 Heat sink temperature (HEATSINK TEMP.) °C 1.2 sec.
538 Alarm word (ALARM WORD [HEX]) Hex code 20 msec.
539 VLT control word (CONTROLWORD [HEX]) Hex code 2 msec.
540 Warning word, 1 (WARN. WORD 1) Hex code 20 msec.
541 Extended status word Hex (EXT. STATUS WORD) Hex code 20 msec.
557 Motor RPM (MOTOR RPM) RPM 80 msec.
558 Motor RPM x scaling (MOTOR RPM X SCALE) - 80 msec.
Function:
These parameters can be read out via the serial com-
munication port and via the display in Display mode,
see also parameters 009 - 012.
Description of choice:
Reference %, parameter 515:
The value shown corresponds to rhe total reference
(sum of digital/analogue/preset/bus/freeze ref./catch-
up and slow-down).
Reference Unit, parameter 516:
Gives the present value of terminals 17/29/53/54/60 in
the unit resulting from the choice of configuration in
parameter 100 (Hz, Nm or rpm) or in parameter 416.
See also parameters 205 and 416, if required.
Feedback, parameter 517:
Indicates the status value of terminals 33/53/60 at the
unit/scale selected in parameters 414, 416 and 416.
Frequency, parameter 518:
The value shown corresponds to the actual motor fre-
quency f
M
(without resonance dampening).
Frequency x scale, parameter 519:
The value shown corresponds to the actual motor fre-
quency f
M
(without resonance dampening) multiplied
by a factor (scaling) set in parameter 008.
VLT
®
5000 Series
= factory setting, () = display text, [] = value for use in communication via serial communication port
144 MG.51.C5.22 - VLT
p
is a registered Danfoss trademark.
