Dell 0403X User Manual

Table 5. Memory specifications(continued)
Description Values
● 8 GB: 1 x 8 GB, DDR5, 5600 MT/s, UDIMM, single-channel
● 16 GB: 1 x 16 GB, DDR5, 5600 MT/s, UDIMM, single-
channel
● 16 GB: 2 x 8 GB, DDR5, 5600 MT/s, UDIMM, dual-channel
● 32 GB: 1 x 32 GB, DDR5, 5600 MT/s, UDIMM, single-
channel
● 32 GB: 2 x 16 GB, DDR5, 5600 MT/s, UDIMM, dual-
channel
● 64 GB: 2 x 32 GB, DDR5, 5600 MT/s, UDIMM, dual-
channel
Memory matrix
The following table lists the memory configurations supported on your OptiPlex Small Form Factor 7020.
Table 6. Memory matrix
Configuration Slot
UDIMM1 UDIMM2
8 GB DDR5 8 GB
16 GB DDR5 16 GB
16 GB DDR5 8 GB 8 GB
32 GB DDR5 32 GB
32 GB DDR5 16 GB 16 GB
64 GB DDR5 32 GB 32 GB
External ports
The following table lists the external ports of your OptiPlex Small Form Factor 7020.
Table 7.
External ports
Description Values
Network port
One RJ-45 port 10/100/100 Mbps
USB ports
● Two USB 2.0 (480 Mbps) ports
● One USB 3.2 Gen 1 (5 Gbps) port
● One USB 3.2 Gen 1 Type-C (5 Gbps) port
NOTE: This port does not support video/audio
streaming.
● Two USB 2.0 (480 Mbps) with SmartPower On ports
● Two USB 3.2 Gen 1 (5 Gbps) ports
Audio port
One Universal audio port
Video port
● One optional port (HDMI 2.1/DisplayPort 1.4a (HBR3
support)/VGA)
NOTE: The maximum resolution supported by optional
port is
○ HDMI 2.1 port: Up to 4096x2160 @60Hz.
Specifications of OptiPlex Small Form Factor 7020 21
