Product Dell
5524 & 5524P Dell
5548 & 5548P
Port types
24 10/100/1000BASE-T auto-sensing Gigabit Ethernet
switching ports; 2 SFP+ ports for fiber media support; 2 HDMI
Stacking Ports 5524P: Up to 15.4 watts per port on all 24 ports
48 10/100/1000BASE-T auto-sensing Gigabit Ethernet switching
ports; 2 SFP+ ports for fiber media support; 2 HDMI Stacking Ports
5548P: Up to 15.4 watts per port (with optional external power
supply) on all 48 ports
Performance
Switch Fabric Capacity 128.0 Gb/s
Forwarding Rate 65.47 Mpps
Up to 16,000 MAC Addresses
Switch Fabric Capacity 176.0 Gb/s
Forwarding Rate 100.2 Mpps
Up to 16,000 MAC Addresses
Port configuration
Auto-negotiation for speed, duplex mode and flow control
Auto MDI/MDIX
Port mirroring
Broadcast storm control
Energy Ecient Ethernet (IEEE802.3az) per port settings
Port profiles- predefined macros to help automatically configure ports.
Up to 64 Static Routes Supported
Management
Web-based management interface
Industry-standard CLI accessible via Telnet or Local Serial Port
SNMPv1, SNMP v2c, SNMPv3 supported
USB Drive Support: Auto-Configuration, Firmware
4 RMON groups supported (history, statistics, alarms, and events)
TFTP transfers of firmware and configuration files
Dual firmware images on-board
Multiple configuration file upload/download supported
Statistics for error monitoring and performance optimization including port summary tables
BootP/DHCP IP address management supported
Syslog remote logging capabilities
LLDP-MED
SNTP
iSCSI Auto Configuration
Quality of Service
8 priority queues per port
Layer 2 Trusted Mode (IEEE 802.1p tagging), Layer 3 Trusted Mode (DSCP)
Adjustable Weighted-Round-Robin (WRR) and Strict Queue Scheduling
IPv4 and IPv6 support
Security
Switch access password protection, including strong password support
User-definable settings for enabling or disabling Web, SSH, Telnet, SSL management access
Port-based MAC Address alert and lock-down
IP Address filtering for management access via Telnet, HTTP, HTTPS/SSL, SSH, and SNMP
RADIUS and TACACS+ remote authentication for switch management access
SSLv3 and SSHv2 encryption for switch management trac
Management access filtering via Management Access Profiles
IEEE 802.1x–based edge authentication
802.1x monitor mode to aid in .1x troubleshooting
MAC and IP based ACLs, Time controlled ACLs
Dynamic ARP Inspection
VLAN
IEEE 802.1Q tagging and port-based, up to 4,000 user-configurable VLANs
Protocol-based VLANs
Dynamic VLANs with GVRP support
Multicast
IGMP v1/v2/v3 snooping
IGMP snooping for IP multicast support
IGMP Querier
Static IP Multicast
Switching features
Link Aggregation with support for up to 32 aggregated links per switch and up to 8 member ports per aggregated link (IEEE 802.3ad)
LACP support (IEEE 802.3ad)
Port mirroring
Jumbo frame support up to 10K
DHCP Server support, DHCP Snooping, DHCP Relay
Availability
External redundant power support with RPS-720 (sold separately), MPS-600 (sold separately)
Spanning Tree (IEEE 802.1D) and Rapid Spanning Tree (IEEE 802.1w) with Fast Link support
Spanning Tree optional features – STP root guard, BPDU guard, BPDU filtering
Dual firmware images
Configuration file upload and download
Switch Auditing support
sFlow
Chassis
5524, 5548:
* 440 x 255 x 43.2 mm (W x D x H)
* 17.32 x 10.03 x 1.7 in (W x D x H)
* 1U, rack-mounting kit included
* Approximate weight: 3.33 kg / 7.35 lb
5524P, 5548P:
* 440 x 381 x 43.2 mm (W x D x H)
* 17.32 x 15 x 1.7 in (W x D x H)
* 1U, rack-mounting kit included
* Approximate weight: 6.1 kg / 13.45 lb
Power
Internal Power Supply Voltage AC 110/240 V +- 10% (50/60Hz)
Power Consumption Max (Watts): 5524 (29.4W); 5524P (380W, all ports as PoE); 5548 (48.8W); 5548P (542.1W, All ports as PoE)
Peripheral products
RPS-720 Redundant Power Supply (5524, 5548), MPS-600 (5524P, 5548P)
Dell SFP Transceivers (1000-SX and 1000-LX), Dell SFP+ Transceivers (SR, LR, LRM, Twin-ax)
See all networking products at Dell.com/Networking
January 2014 | Version 2.1
dell-networking-5000-series-spec-sheet
Models available with US Trade Agreements Act (TAA) compliance.
©2014 Dell Inc. All rights reserved. Dell, the DELL logo and the DELL badge are trademarks of Dell Inc. Other trademarks and trade names may be used in this
document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the marks and names of others.
This document is for informational purposes only. Dell reserves the right to make changes without further notice to the products herein. The content provided
is as-is and without expressed or implied warranties of any kind.
*PoE models fully support end-point devices running the IEEE 802.3af PoE standard but may not support pre-standard end-point devices.
**Select Dell Networking products carry a Lifetime Limited Warranty with Basic Hardware Service (repair or replacement) for life. Repair or replacement does
not include troubleshooting, configuration, or other advanced service provided by Dell ProSupport. For more details see dell.com/lifetimewarranty.
