Dell UPS Site Preparation Guide, EMEA (230V) Revision 1, February 2012
Site Preparation:
Physical Requirements for the Dell UPS
UPS Model
UPS Technology
Dimensions (mm, W x D x H)
Weight (installed, no battery)
3750W Rack
Online
4U, 438 x 790 x 171.5
65kg, 23kg
4200W Rack
Online
4U, 438 x 790 x 171.5
65kg, 23kg
5600W Rack
Line-Interactive
4U, 438 x 790 x 171.5
72kg, 24kg
5600W Rack
Online
4U, 438 x 790 x 171.5
64kg, 24kg
EBM* for 3750W/4200W UPS
n/a
3U, 438 x 735 x 127
61kg, n/a
EBM* for all 5600W UPS
n/a
4U, 438 x 735 x 171.5
66kg, n/a
* EBM is an optional ‘external battery module’.
Environmental Requirements for the Dell UPS
Environmental Condition
Suitable Range
Temperature (Operation)
0 - 40C (32 - 104F)
Temperature (Storage, 24hr)
-15 - 60C (5 - 140F)
Temperature (Long-term Storage)
- 15 - 45C (5 - 113F)
Relative Humidity
0 - 95% (non-condensing)
Elevation (Operation)
0-3048m (0 - 10,000ft)
Elevation (Storage)
0 - 15,340m (0 - 50,000ft)
Heat Output for the Dell UPS
UPS Model
UPS Technology
Heat Loss, Watts / BTU (normal mode)
Heat Loss, Watts / BTU (battery mode)
3750W Rack
Online
188 / 640
375 / 1281
4200W Rack
Online
210 / 717
420 / 1434
5600W Rack
Line-Interactive
280 / 956
560 / 1921
5600W Rack
Online
390 / 989
420 / 1433
Optional accessories for Dell UPS
Optional Accessory
Importance
Purpose & Use
External Battery Module
Optional
Increases the battery runtime (autonomy) by approximately 3 times
Network Management Card
Recommended
Improves communication with >1 server and is mandatory for
virtualization
Environmental Monitoring Probe
Recommended
Measures rack temperature and humidity (plus 2 x relay contacts).
Requires network management card. Data rolls up into UPS Management
software.
32A, 3m Electrical Input Cord
Highly Recommended
UPS input cable pack providing a 3m cord with IEC309 32A Commando
plug. Also includes plastic stuffing gland (strain relief).
