Machine overview
18
1. Introduction
10
Front view
• This illustration may differ from your machine depending on your model.
There are various types of machine.
• Some features and optional goods may not be available depending on
model or country (see "Features by models" on page 7).
Type A
1 Scanner lid 7 Output tray
7
6
1
2
5
4
8
9
10
11
3
2 Control panel 8 Scanner glass
3
Handle
9
Scan unit
a b
4 Tray 10 Inner cover
5 Tray handle 11 Toner cartridge
6 Output support
a. Close the scanner lid before opening the scan unit.
b. Be careful not to pinch your fingers.
