Dell Inspiron 7415 2-in-1 User Manual

7. Install the base cover.
8. Follow the procedure in After working inside your computer.
Palm-rest and keyboard assembly
Removing the palm-rest and keyboard assembly
Prerequisites
1. Follow the procedure in Before working inside your computer.
2. Remove the base cover.
3. Remove the battery.
4. Remove the coin-cell battery.
5. Remove the memory modules.
6. Remove the wireless card.
7. Remove the M.2 2230 solid-state drive or M.2 2280 solid-state drive, whichever applicable.
8. Remove the I/O board.
9. Remove the speakers.
10. Remove the heat sink.
11. Remove the fan.
12. Remove the touchpad.
13. Remove the power button or power button with fingerprint reader.
14. Remove the display assembly.
15. Remove the system board.
NOTE: The system board can be removed along with the heat sink.
About this task
The following image indicates the location of the palm-rest and keyboard assembly and provides a visual representation of the
removal procedure.
58
Removing and installing components

Dell Inspiron 7415 2-in-1 Specifications

General

Graphics	AMD Radeon Graphics
Processor	AMD Ryzen 5 5500U
Display	14.0-inch FHD (1920 x 1080)
RAM	8GB DDR4 3200MHz
Storage	256GB M.2 PCIe NVMe SSD
Operating System	Windows 10 Home
Battery	4-Cell, 54WHr Integrated Battery
Ports	2 x USB 3.2 Gen 1 Type-A, 1 x USB 3.2 Gen 1 Type-C, 1 x HDMI 1.4b, 1 x Headset Jack
Webcam	720p at 30 fps HD camera
Audio	Stereo speakers, Waves MaxxAudio Pro
