Replacing the Palm Rest
1. Align the palm rest with the computer base and gently snap into place.
2. Connect the touch pad connector to the system board.
3. Connect the speaker connector.
4. Connect the button board connector.
5. Replace the five M2.5 x 5-mm screws and the M2 x 3-mm screw on the top of the palm rest.
6. Turn the computer over and replace the 12 M2.5 x 5-mm screws in the computer base.
7. Replace the internal card with Bluetooth®wireless technology.
8. Replace the display assembly.
9. Replace the keyboard.
10. Replace the center control cover.
