Dell Latitude D520 User Manual


1. Align the pin-1 corner of the processor module with the pin-1 corner of the ZIF socket, and insert the processor module.
When the processor module is correctly seated, all four corners are aligned at the same height. If one or more corners of the module are higher than the
others, the module is not seated correctly.

2. Tighten the ZIF socket by turning the cam screw clockwise to secure the processor module to the system board.

3. Perform the steps in Removing the Processor Module in reverse order, beginning with step4.
Back to Contents Page

NOTICE: A processor module that is not properly seated can result in an intermittent connection or permanent damage to the processor and ZIF
socket.
NOTE: If a new microprocessor is installed, you will receive one of the following: a new thermal-cooling assembly which will include an affixed thermal
pad; or, you will receive a new thermal pad along with a tech sheet to illustrate proper installation.
NOTE: The pin-1 corner of the processor module has a triangle that aligns with the triangle on the pin-1 corner of the ZIF socket.
NOTICE: You must position the processor module correctly in the ZIF socket to avoid permanent damage to the module and the socket.

Dell Latitude D520 Specifications

General

Processor	Intel Core Duo or Intel Celeron M
Graphics	Intel Graphics Media Accelerator 950
Operating System	Windows XP Professional
Chipset	Intel 945GM Express
Maximum Memory	4 GB
Processor Speed	1.66 GHz
RAM	512 MB to 4 GB
Storage	40 GB to 120 GB HDD
Display	15.4 inch
Display Resolution	1280 x 800 (WXGA)
Optical Drive	DVD-ROM
Battery	6-cell Lithium Ion
Ports	4 x USB 2.0, VGA, Ethernet, Modem
Wireless	802.11a/b/g
