Table 1. Screw list
Component Secured to Screw type Quantity Screw image
Power-adapter port Palm-rest and keyboard
assembly
M2x3 1
Type-C port bracket System board M2x4 2
Display hinges Palm-rest and keyboard
assembly
M2.5x4 4
I/O board Palm-rest and keyboard
assembly
M2x3 1
System board Palm-rest and keyboard
assembly
M2x2 2
Major components of Inspiron 14 5410
The following image shows the major components of Inspiron 14 5410.
Removing and installing components 11
