Dell PowerEdge R410 Specifications

Learn more at Dell.com/PowerEdge
© 2010 Dell Inc. All rights reserved. Dell, the DELL logo, the DELL badge, PowerEdge, and OpenManage are trademarks of Dell Inc. Other trademarks and trade
names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims proprietary interest in the
marks and names of others. This document is for informational purposes only. Dell reserves the right to make changes without further notice to any products
herein. The content provided is as is and without express or implied warranties of any kind.
Feature Technical Specification
Form Factor
2U rack
Processors
Latest quad-core or six-core Intel
®
Xeon
®
processor 5500 and 5600 series
Processor Sockets
2
Front Side Bus or
HyperTransport
Intel
®
QuickPath Interconnect (QPI)
Cache
4MB and 8MB
Chipset
Intel 5500 Chipset
Memory
1
Up to 64GB (8 DIMM slots): 1GB/2GB/4GB/8GB DDR3 800MHz, 1066MHz or 1333MHz
16GB Quad-Ranked 1066MHz DIMMs
I/O Slots
1 PCIe x 16 (True x16, Gen2), 1 Proprietary for SAS 6/iR Modular card only
RAID Controller
Internal:
PERC H200 (6Gb/s)
PERC H700 (6Gb/s) with 512MB battery-backed cache;
512MB, 1GB Non-Volatile battery-backed cache
SAS 6/iR
PERC 6/i with 256MB battery-backed cache
PERC S100 (software based)
PERC S300 (software based)
External:
PERC H800 (6Gb/s) with 512MB of battery-backed cache;
512MB, 1GB Non-Volatile battery cache
PERC 6/E with 256MB or 512MB of battery-backed cache
External HBAs (non-RAID):
6Gbps SAS HBA
SAS 5/E HBA
LSI2032 PCIe SCSI HBA
Drive Bays
4x 3.5” Cabled Hard Drive
Or 4 x 3.5” Hot-swap Hard Drive
Or 4x 2.5” Hot-swap hard Drive
And one slim type drive bay for DVD-ROM or DVD+/-RW
Maximum Internal Storage
Up to 4 TB SATA or Near Line SAS
Hard Drives
1
3.5” SATA ( 7.2K rpm) 160GB, 250GB, 500GB, 750GB, 1TB
3.5” Near Line SAS ( 7.2K rpm) 500GB, 750GB, 1TB
3.5” 6Gps SAS (7.2K): 2TB
3.5” SAS (15K rpm) 146GB, 300GB, 450GB
3.5” SAS (10K rpm) 600GB
3.5” 2.0TB SATA
2.5” SAS (10K rpm) 73GB, 146GB, 300GB
2.5” SATA SSD 25GB, 50GB, 100GB
Communications
Embedded Dual-port Broadcom
®
NetXtreme™ II 5716
Gigabit Ethernet
Intel
®
Gigabit ET Dual Port Server Adapter and Intel
®
Gigabit
ET Quad Port Server Adapter
Intel
®
10GbE NIC
Intel
®
Single Port 1GbE NIC
Intel
®
Dual Port 1GbE NIC
Intel
®
Quad Port 1GbE NIC
Broadcom
®
10GbE NIC
Broadcom
®
Dual Port 1GbE NIC
Brocade
®
CNA Dual-port adapter
Brocade
®
FC4 and 8 GB HBAs
Emulex
®
CNA iSCSI HBA stand up adapter OCE10102-IX-D
Power Supply
Non-Redundant, 480W (80+ BRONZE)
Optional Redundant, 500W (80+ GOLD)
Availability
Quad-pack LED Diagnostic or LCD diagnostic with hot-swap HDD chassis; TPM; optional hot-swap hard drives; optional
hot-swap redundant power supply; optional PERC 6/i RAID controller with battery-backed cache; toolless hot-swap hard
drive chassis
Video
Integrated Matrox
®
G200
Remote Management
BMC, IPMI2.0 compliant
Optional iDRAC6 Enterprise, iDRAC6 Express
Systems Management
Dell™ OpenManage™
Microsoft
®
System Center Essential (SCE) 2010 v2
Rack Support
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for
threaded hole racks); ReadyRails™ static rails for 2-post and 4-post racks
Operating Systems
Microsoft
®
 Windows
®
 Small Business Server 2008
Microsoft
®
 Windows
®
 Essential Business Server 2008
Microsoft
®
Windows Server
®
2008 SP2, x86/x64 (x64 includes Hyper-V™)
Microsoft
®
Windows Server
®
2008 R2, x64 (includes Hyper-V™ v2)
Microsoft
®
 Windows
®
 HPC Server 2008
Novell
®
SUSE
®
Linux
®
Enterprise Server
Red Hat
®
Enterprise Linux
®

For more information on the specific versions and additions, visit www.dell.com/OSsupport.
Featured Database
Application
Microsoft
®
SQL Server
®
solutions (see Dell.com/SQL)
1
GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
OEM Ready Models Available
OEM Ready platforms are grab-and-go products for OEM customers delivering a fast and simple
path to a custom-branded solution. For more information, please visit dell.com/OEM.

Dell PowerEdge R410 Specifications

General

Tcase	76 °C
Bus type	QPI
Stepping	D0
FSB Parity	No
Processor code	SLBF9
Processor cache	4 MB
Processor cores	4
Processor model	E5504
System bus rate	4.8 GT/s
Processor series	Intel Xeon 5500 Series
Processor socket	Socket B (LGA 1366)
Processor codename	Nehalem EP
Motherboard chipset	Intel® 5500
Number of QPI links	2
Processor frequency	2 GHz
Processor cache type	Smart Cache
Processor lithography	45 nm
Processor system type	DP
Processor manufacturer	Intel
Processor package size	42.5 x 45 mm
Processor front side bus	- MHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Thermal Design Power (TDP)	80 W
Number of processors installed	1
CPU multiplier (bus/core ratio)	15
Memory types supported by processor	DDR3-SDRAM
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800 MHz
Memory bandwidth supported by processor (max)	19.2 GB/s
Maximum internal memory supported by processor	144 GB
HDD size	3.5 \
HDD capacity	250 GB
Optical drive type	DVD-ROM
Total storage capacity	500 GB
Maximum storage capacity	8 TB
Memory slots	8x DIMM
Internal memory	8 GB
Memory clock speed	1066 MHz
Internal memory type	-
Maximum internal memory	128 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Graphics card	G200eW
Networking features	Gigabit Ethernet
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	480 W
Compatible operating systems	Microsoft SQL Server 2008 R2/Windows Small Business Server 2008/Essential Business Server 2008/Server 2008 SP2, x86/x64/Server 2008 R2/HPC Server 2008; Novell SUSE Linux Enterprise Server; Red Hat Enterprise Linux.
Chassis type	Rack (1U)
Processor ARK ID	40711

Weight and Dimensions

Depth	430 mm
Width	630 mm
Height	40 mm
