Dell PowerEdge R610 Datasheet

Learn more at Dell.com/PowerEdge
© 2012 Dell Inc. All rights reserved. Dell, the DELL logo, the DELL badge, PowerEdge, ReadyRails, and OpenManage are trademarks of Dell Inc. Other
trademarks and trade names may be used in this document to refer to either the entities claiming the marks and names or their products. Dell disclaims
proprietary interest in the marks and names of others. This document is for informational purposes only. Dell reserves the right to make changes without further
notice to any products herein. The content provided is as is and without express or implied warranties of any kind.
Feature PowerEdge R610 Technical Specification
Form Factor
1U rack
Processors
Quad-core or six-core Intel
®
Xeon
®
processors 5500 and 5600 series
Processor Sockets
2
Front Side Bus or
HyperTransport
Intel QuickPath Interconnect (QPI)
Cache
4MB and 8MB
Chipset
Intel 5520
Memory
1
Up to 192GB (12 DIMM slots): 1GB/2GB/4GB/8GB/16GB DDR3 up to 1333MT/s
I/O Slots
2 PCIe 2.0 slots + 1 storage slot: two x8 slots, one storage x4 slot
RAID Controller
Internal:
PERC H200 (6Gb/s)
PERC H700 (6Gb/s) with 512MB battery-backed cache;
512MB, 1GB Non-Volatile battery-backed cache
SAS 6/iR
PERC 6/i with 256MB battery-backed cache
External:
PERC H800 (6Gb/s) with 512MB of battery-backed cache;
512MB, 1GB Non-Volatile battery-backed cache
PERC 6/E with 256MB or 512MB of battery-backed cache
External HBAs (non-RAID):
6Gbps SAS HBA
SAS 5/E HBA
LSI2032 PCIe SCSI HBA
Drive Bays
Internal hard drive bay and hot-plug backplane
Up to six 2.5” SAS or SSDs
Maximum Internal Storage
1
Up to 12TB
Hard Drives
Hot-plug hard drive options:
2.5” SAS SSD, SATA SSD, SAS (10K, 15K), nearline SAS (7.2K), SATA (7.2K)
Solid state storage cards:
Fusion-io
®
160GB ioDrive PCIe solid state storage card
Fusion-io 640GB ioDrive Duo PCIe solid state storage card
Fusion-io 320GB ioDrive Mono PCIe solid state storage card
Fusion-io 640GB ioDrive Mono PCIe solid state storage card
Fusion-io 1.28TB ioDrive Mono PCIe solid state storage card
Communications
Two dual port embedded Broadcom
®
NetXtreme
®
II 5709c
Gigabit Ethernet NIC with failover and load balancing.
Optional 1GBe and 10GBe add-in NICs
Broadcom NetXtreme II 57711 Dual Port Direct Attach 10Gb
Ethernet PCI-Express Network Interface Card with TOE and
iSCSI Ooad
Intel Gigabit ET Dual Port Server Adapter and Intel Gigabit
ET Quad Port Server Adapter
Dual Port 10GB Enhanced Intel Ethernet Server Adapter
X520-DA2 (FCoE Ready for Future Enablement)
Brocade
®
CNA Dual-port adapter
Emulex
®
CNA iSCSI HBA stand up adapter OCE10102-IX-D
Emulex CNA iSCSI HBA stand up adapter OCE10102-FX-D
Emulex OCE10102-IX-DCNA iSCSI HBA stand-up adapter
Optional add-in HBAs:
Brocade 8GB HBAs
Power Supply
Two hot-plug high-ecient 502W Energy Smart PSU or two hot-plug 717W High Output PSUs
Uninterruptible Power Supplies:
1000W-5600W
2700W-5600W High Eciency Online
Extended Battery Module (EBM)
Network Management Card
Availability
DDR3 memory; ECC; hot-plug hard drives; optional hot-plug redundant power supplies; dual embedded NICs with
failover and load balancing support; optional PERC6/i integrated daughter card controller with battery-backed cache;
hot-plug redundant cooling; tool-less chassis; fibre and SAS cluster support; validated for Dell/EMC SAN
Video
Integrated Matrox
®
G200, 8MB shared video memory
Remote Management
iDRAC6 Enterprise (optional)
Systems Management
Dell™ OpenManage™
Embedded Hypervisor
Optional Embedded SD Media
Rack Support
ReadyRails™ sliding rails with optional cable management arm for 4-post racks (optional adapter brackets required for
threaded hole racks); ReadyRails static rails for 2-post and 4-post racks
Operating Systems
Microsoft
®
Windows Server
®
2012
Microsoft Windows Server 2012 Essentials
Small Business Server 2011
MicrosoftWindowsSmall Business Server 2008
Microsoft Windows Server 2008 SP2, x86/x64 (x64 includes
Hyper-V
®
)
Microsoft Windows Server 2008 R2 SP1, x64 (includes
Hyper-V v2)
Microsoft Windows HPC Server 2008 R2
Novell
®
SUSE
®
Linux Enterprise Server
Red Hat
®
Enterprise Linux
®
Oracle
®
Solaris™
Virtualization options:
Citrix
®
XenServer
®
VMware
®
vSphere
®
ESX™ and ESXi™
Red Hat Enterprise Virtualization
®
For more information on the specific versions and
additions, visit Dell.com/OSsupport.
Featured Database
Applications
Microsoft SQL Server
®
solutions (see Dell.com/SQL)
Oracle database solutions (see Dell.com/Oracle)
Thermal Operation
Continuous Operation: 10C to 35C, 10% to 80% relative humidity (RH). 10% of annual operating hours: 5C to 40C, 5% to
85%RH. 1% of annual operating hours: -5C to 45C, 5% to 90%RH. For in-depth detail, check your user manual.
1
GB means 1 billion bytes and TB equals 1 trillion bytes; actual capacity varies with preloaded material and operating environment and will be less.
OEM Ready Models Available
OEM Ready platforms are grab-and-go products for OEM customers delivering a fast and simple
path to a custom-branded solution. For more information, please visit Dell.com/OEM.

Dell PowerEdge R610 Specifications

General

Tcase	77.6 °C
Bus type	QPI
Stepping	B1
FSB Parity	No
Processor code	SLBV4
Processor cache	12 MB
Processor cores	4
Processor model	E5620
System bus rate	5.86 GT/s
Processor series	Intel Xeon 5600 Series
Processor socket	Socket B (LGA 1366)
Processor threads	8
Processor codename	Westmere EP
Motherboard chipset	Intel® 5520
Number of QPI links	2
Processor frequency	2.4 GHz
Processor cache type	Smart Cache
Processor lithography	32 nm
Processor manufacturer	Intel
Processor package size	42.5 X 45 mm
Processor front side bus	- MHz
Processor boost frequency	2.66 GHz
Processor operating modes	64-bit
ECC supported by processor	Yes
Supported instruction sets	SSE4.2
Thermal Design Power (TDP)	80 W
Compatible processor series	Intel® Xeon®
Number of processors installed	1
CPU multiplier (bus/core ratio)	18
Physical Address Extension (PAE)	40 bit
Memory types supported by processor	DDR3 800/1066
Memory channels supported by processor	Triple
Memory clock speeds supported by processor	800, 1066 MHz
Memory bandwidth supported by processor (max)	25.6 GB/s
Maximum internal memory supported by processor	288 GB
HDD size	2.5 \
HDD speed	15000 RPM
HDD interface	Serial Attached SCSI (SAS)
Optical drive type	DVD-RW
Total storage capacity	146 GB
Maximum storage capacity	12 TB
Number of HDDs supported	6
Graphics card	G200
Graphics card family	Matrox
Memory slots	12
Internal memory	8 GB
Memory clock speed	1333 MHz
Internal memory type	DDR3-SDRAM
Maximum internal memory	192 GB
Memory layout (slots x size)	4 x 2 GB
Maximum graphics card memory	8 MB
Networking features	Gigabit Ethernet
Ports quantity	11
Number of slots	3
PS/2 ports quantity	0
USB 2.0 ports quantity	USB 2.0 ports have a data transmission speed of 480 Mbps, and are backwards compatible with USB 1.1 ports. You can connect all kinds of peripheral devices to them.
Power supply	717 W
Operating system installed	-
Compatible operating systems	SQL Server 2008 R2 Windows Small Business Server 2008 Windows Essential Business Server 2008 Windows Server 2008 SP2, x86/x64 (x64 Hyper-V) Windows Server 2008 R2, x64 (Hyper-V v2) Windows HPC Server 2008 SUSE Linux Enterprise Server Red Hat Enterprise Linux Sun Solaris
Sustainability certificates	ENERGY STAR
Compliance industry standards	IEEE 802.3, IEEE 802.3u, IEEE 802.3ab
Chassis type	Rack (2U)
Processor ARK ID	47925
Intel® Turbo Boost Technology	1.0

Weight and Dimensions

Depth	772 mm
Width	482 mm
Height	42.6 mm
Weight	17690 g
