Dell S3422DW User Manual

About your monitor │ 11
Back view
3
5
4
2
1
SVC Tag:
1234567
Express Service
Code:
123 456 789 0
S/N: CN-0M2TMK
-TV100-04F-001V
-A00
Date of Mfg/⭕ӝᰛᵕ⭕⭘ᰛᵕ: April. 2020
Q40G034N-700-02A
Flat Panel Monitor /⏨Წᱴ⽰ಞ
ශ:S3421DW
Input Rang /䗉ޛ⭫Ⓠ:
100-240V 50/60Hz,1.6A
Made in China /ѣള࡬䙖
DELL S3421DW
Q40G034N-700-01A
DELL S3421DW
Flat Panel Monitor /Monitor Plano Panel /Moniteur écran plat /⏢Ღ亟⽪ಘ
Model No. /Modelo /N°de modelo /ර㲏: S3421DWc
Input Rang /Entrade /Daya Tegangan:100-240V 50/60Hz,1.6A
䕨ޕ䴫ⓀӔ⍱䴫༃100-240Կ⢩,1.6ᆹษ,50/60䎛㥢
Consumo de energía en operación: XXX Wh
Удельная мощность рабочего режима - XXX Вт/см²
Потребляемая мощность изделием в режиме ожидания - XXX Вт
Потребляемая мощность изделием в выключенном режиме - XXX Вт
Apparatet må lkoples jordet skkontakt.
Apparaten skall anslutas ll jordat uag.
Laite on liiteävä suojakoskemilla varusteuun pistorasiaan.
Apparatets skprop skal lslues en skkontakt med jord,
som giver forbindelse l skproppens jord.
The equipment must be connected to an earthed mains socket-outlet.
L'appareil doit être branché sur une prise de courant munie d'une mise à la terre.
сделанный в Китай /Fabriqué en Chine /ѣു㼳䙖䆜䃔ֵ⭞䚄ᓜᚆۭᇩ㿌࣑Ⱦ
www.dell.com/regulatory_compliance Raheen Business Park Limerick Ireland (for EU Only)
CAN ICES-3 (B)/NMB-3(B)
This device complies with part 15 of the FCC Rules. Operaon is subject to the following two condions:
(1) this device may not cause harmful interference, and
(2) this device must accept any interference received, including interference that may cause undesired operaon.
XXXXXXX-XXXXX
R-R-TPF-S3421DWc
㥐㦤㣄ڊ㐔㷡㢬ڕTPV Electronics (Fujian) Co., Ltd.
080-200-3800
R33037
RoHS
IS 13252 (Part 1)/
IEC 60950-1
R-41018660
www.bis.gov.in
For UK only: Cain Road, Bracknell, RG12 1LF
20
XXXXX
䝕
ޛ࣑100 V, 1.6 A, 50/60 Hz
XXXXX-XX
Made in China
Back View with monitor stand
Label Description Use
1 Cable management slot Organizes the cables when the cables
are routed through the slot.
2 VESA mounting holes (behind
VESA cover)
VESA mounting holes (100 mm x
100 mm). Use for Wall mounting the
monitor through a VESA-compatible
wall mount kit.
3 Regulatory information label Lists the regulatory approvals.
4 Stand release button Releases stand from monitor.
5 Regulatory label (including
Barcode serial number and
Service Tag label)
Lists the regulatory approvals. Refer
to this label if you need to contact
Dell for technical support.The Service
Tag is a unique alphanumeric identifier
that enables Dell service technicians
to identify the hardware components
in your computer and access warranty
information.

Dell S3422DW Specifications

General

Panel type	VA
Color gamut	89.2 %
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99.7 %
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	2.2
Headphone out	-
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	92 W
Power consumption (off)	0.3 W
Power consumption (typical)	32 W
Package depth	949.96 mm
Package width	468.12 mm
Package height	225.04 mm
Package weight	14950 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Product color	Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	10 W
Cables included	AC, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	210 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9800 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.01 mm
Height (without stand)	364.5 mm
Weight (without stand)	6700 g
