Dell S3422DW User Manual

8 │ About your monitor
USB 3.0 upstream cable
(enables the USB ports on the
monitor)
∞
Quick Setup Guide
∞
Safety and Regulatory
Information
Product features
The Dell S3422DW monitor has an active matrix, Thin-Film Transistor (TFT), Liquid
Crystal Display (LCD), anti-static, and LED backlight. The monitor features include:
∞
86.42 cm (34.0 in.) viewable area display (measured diagonally). 3440 x 1440
resolution, with full-screen support for lower resolutions.
∞
Compatible with (AMD FreeSync™ or No Sync), high refresh rates and a rapid
response time of 4 ms.
∞
Supports 48 Hz to 144 Hz (HDMI) and 48 Hz to 164 Hz (DP) in Freesync Mode.
∞
Build-in Speaker (5 W) x 2
∞
Color gamut of 99% sRGB.
∞
Digital connectivity with DP and HDMI.
∞
Equipped with 1 USB upstream port and 2 USB downstream ports.
∞
Plug and play capability if supported by your computer.
∞
On-Screen Display (OSD) adjustments for ease of setup and screen optimization.
∞
Removable stand and Video Electronics Standards Association (VESA™) 100 mm
mounting holes for flexible mounting solutions.
∞
Tilt and height adjustment capabilities.
∞
Security-lock slot.
∞
≤0.3 W in the Standby Mode
∞
Dell Display Manager Software included.
∞
Optimize eye comfort with a flicker-free screen.
WARNING: The possible long-term effects of blue light emission from

Dell S3422DW Specifications

General

Panel type	VA
Color gamut	89.2 %
Pixel pitch	0.23175 x 0.23175 mm
Pixel density	109 ppi
Backlight type	LED
Display diagonal	34 \
Anti-glare screen	Yes
Display technology	LCD
Native aspect ratio	21:9
Vertical scan range	48 - 100 Hz
Horizontal scan range	30 - 160 kHz
Supported video modes	480i, 480p, 576p, 720p, 1080i, 1080p
Viewable size diagonal	864.2 mm
Viewable size, vertical	333.7 mm
sRGB coverage (typical)	99.7 %
Display number of colors	16.7 million colors
Display diagonal (metric)	86.42 cm
Viewable size, horizontal	797.2 mm
Display brightness (typical)	300 cd/m²
Tilt angle range	-5 - 21 °
Panel mounting interface	100 x 100 mm
HDMI version	2.2
Headphone out	-
USB hub version	2.0 / 3.2 Gen 1 (3.1 Gen 1)
DisplayPort version	1.2
USB upstream port type	USB Type-B
VGA (D-Sub) ports quantity	0
AC input voltage	100 - 240 V
Power supply type	Internal
AC input frequency	50 - 60 Hz
Power consumption (max)	92 W
Power consumption (off)	0.3 W
Power consumption (typical)	32 W
Package depth	949.96 mm
Package width	468.12 mm
Package height	225.04 mm
Package weight	14950 g
Doesn't contain	PVC/BFR
Sustainability certificates	RoHS
Product color	Silver
Front bezel color	Black
Heavy metals free	Hg (mercury)
Market positioning	Business
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	10 - 90 %
Operating relative humidity (H-H)	10 - 80 %
RMS rated power	10 W
Cables included	AC, HDMI, USB
Harmonized System (HS) code	85285210

Weight and Dimensions

Bezel width (top)	8.64 mm
Bezel width (side)	8.65 mm
Depth (with stand)	210 mm
Width (with stand)	808.16 mm
Height (with stand)	489.36 mm
Weight (with stand)	9800 g
Bezel width (bottom)	22.14 mm
Depth (without stand)	64.01 mm
Height (without stand)	364.5 mm
Weight (without stand)	6700 g
