Dell U2717D User Manual

Operating the Monitor | 33
The following table describes the front panel buttons:
Front-Panel Button Description
1
Shortcut key:
Preset Modes
Use this button to choose from a list of preset
colormodes.
2
Shortcut key:
Input Source
Use this button to choose from a list of Input Source.
3
Menu
Use this menu button to launch the on-screen
display (OSD) and select the OSD menu.
See Accessing the Menu System.
4
Exit
Use this button to go back to the main menu or exit
the OSD main menu.
5
Power (with power light
indicator)
Use the Power button to turn the monitor On and
Off.
The white LED indicates the monitor is On and fully
functional.
A glowing white LED indicates DPMS Power Save
Mode.

Dell U2717D Specifications

General

3D	No
Color gamut	99 %
Pixel pitch	0.2331 x 0.2331 mm
Aspect ratio	-
Screen shape	Flat
Response time	8 ms
SmartResponse	6 ms
Display surface	Matt
Display diagonal	27 \
Display technology	LED
Vertical scan range	50 - 75 Hz
Horizontal scan range	30 - 88 kHz
Supported video modes	480i, 480p, 576i, 576p, 720p, 1080i, 1080p, 1440p
Viewable size, vertical	335.664 mm
Contrast ratio (typical)	1000:1
Display number of colors	16.78 million colors
Viewable size, horizontal	569.736 mm
Display brightness (typical)	350 cd/m²
Supported graphics resolutions	2560 x 1440
On/off switch	Yes
USB hub version	3.2 Gen 1 (3.1 Gen 1)
Number of upstream ports	1
VGA (D-Sub) ports quantity	0
USB Type-A downstream ports quantity	4
Certification	TCO, RoHS
Product color	Black
Market positioning	Business
Pivot angle	0 - 180 °
Panel mounting interface	100 x 100 mm
Input current	1.7 A
AC input voltage	100 - 240 V
AC input frequency	50 - 60 Hz
Power consumption (max)	74 W
Power consumption (off)	0.3 W
Power consumption (standby)	0.5 W
Power consumption (typical)	26 W
Power consumption (PowerSave)	21.7 W
Operating altitude	0 - 5000 m
Non-operating altitude	0 - 12192 m
Storage temperature (T-T)	-20 - 60 °C
Operating temperature (T-T)	0 - 40 °C
Storage relative humidity (H-H)	5 - 90 %
Operating relative humidity (H-H)	10 - 80 %
Sustainability certificates	EPEAT Gold, ENERGY STAR
Package weight	9900 g
Cables included	AC, DisplayPort, USB

Weight and Dimensions

Depth (with stand)	200.3 mm
Height (with stand)	540.2 mm
Weight (with stand)	7300 g
Depth (without stand)	48.3 mm
Width (without stand)	611.3 mm
Height (without stand)	355.6 mm
Weight (without stand)	4500 g
