Network Administration: Port Settings 175
FILE LOCATION: C:\Users\gina\Desktop\Checkout_new\Dell Astute\User
Guide\Dell_Astute_Network_Admin_PortSettings.fm
DELL CONFIDENTIAL – PRELIMINARY 8/9/16 - FOR PROOF ONLY
To configure dynamic addresses:
1
Click
Network Administration > Port Settings >
Dynamic Address
Table
.
The current address table is displayed along with other parameters.
2
Click
Edit
,
Settings Icon
().
3
Enter
Address Aging (sec)
. The aging time is a value between the user-
configured value and twice that value minus 1. For example, if you entered
300 seconds, the aging time is between 300 and 599 seconds.
4
Click
OK
.
5
To clear the table, check
Clear Table
.
6
To display a subset of the addresses in a particular order, click the
Filter
icon and enter the following query criteria:
–
Interface
— Port or LAG associated with the MAC address.
–MAC Address
— Interface MAC address.
–
VLAN ID
— VLAN ID in the entry.
7
Click
Query
to see the results.
UDLD
This section describes how the Unidirectional Link Detection (UDLD)
feature.
It covers the following topics:
•Overview
• UDLD Global Settings
• UDLD Interface Settings
• UDLD Neighbors
Overview
Unidirectional Link Detection (UDLD) is a Layer 2-protocol that enables
devices connected through fiber-optic or twisted-pair Ethernet cables to
detect unidirectional links. A unidirectional link occurs whenever traffic from
a neighboring device is received by the local device, but traffic from the local
device is not received by the neighbor.
