3
4 Specifications
5
Temperature Sensor Type and Temperature Range
Input Temperature Sensor
Type
Register Value LED Display Temperature Range
0~50mV Analog Input 17
-999 ~ 9999
4~20mA Analog Input 16
-999 ~ 9999
0~20mA Analog Input 15
-999 ~ 9999
0V~10V Analog Input 14
-999 ~ 9999
0V~5V Analog Input 13
-999 ~ 9999
Platinum Resistance (Pt100) 12
-200 ~ 600
o
C
Platinum Resistance (JPt100) 11
-20 ~ 400
o
C
Thermocouple TXK type 10
-200 ~ 800
o
C
Thermocouple U type 9
-200 ~ 500
o
C
Thermocouple L type 8
-200 ~ 850
o
C
Thermocouple B type 7
100 ~ 1800
o
C
Thermocouple S type 6
0 ~ 1700
o
C
Thermocouple R type 5
0 ~ 1700
o
C
Thermocouple N type 4
-200 ~ 1300
o
C
Input Voltage 100 to 240VAC 50/60Hz
Operation Voltage
Range
85% to 110% of rated voltage
Power Consumption 5VA max.
Memory Protection EEPROM 4K bit (non-volatile memory (number of writes: 100,000)
Display Method
2 line x 4 character 7-segment LED display Process value(PV): Red color, Set point(SV):
Green color
Thermocouple: K, J, T, E, N, R, S, B, L, U, TXK
3-wire Platinum RTD: Pt100, JPt100
Sensor Type
Analog input: 0~5V, 0~10V, 0~ 20 m A, 4~20 m A, 0~50mV
Control Mode PID, ON/OFF, Manual or PID program control (Ramp/Soak control)
Relay output: SPDT (SPST: 1/16 DIN and 1/32 DIN size), Max. load 250VAC, 5A resistive load
Voltage pulse output: DC 14V, Max. output current 40mA
Current output: DC 4 ~ 20m A output (Load resistance: Max. 600Ω)
Control Output
Linear voltage output: 0~5V, 0~10V
Display Accuracy 0 or 1 digit to the right of the decimal point (selectable)
Sampling Rate Analog input: 150 msec/ per scan Thermocouple or Platinum RTD: 400 msec/per scan
RS-485 Communication MODBUS ASCII / RTU communication protocol
Vibration Resistance 10 to 55Hz, 10m/s
2
for 10min, each in X, Y and Z directions
Shock Resistance Max. 300m/ s
2
, 3 times in each 3 axes, 6 directions
Ambient Temperature 0
o
C to +50
o
C
Storage Temperature -20
o
C to +65
o
C
Altitude 2000m or less
Relative Humidity 35% to 80% (non-condensing)
