AVR-3805 / AVC-3890
PARTS LIST OF EXPLODED VIEW
Ref. No. Part No. Part Name Remarks Q'ty New
1 1U-3469N POWER UNIT ASS'Y for EU,EC 1 *
1 1U-3469Q POWER UNIT ASS'Y for E2,E2A 1 *
1 1U-3469U POWER UNIT ASS'Y for E1C,E1K 1 *
1 1U-3469S POWER UNIT ASS'Y for EUT 1 *
1 1U-3469R POWER UNIT ASS'Y for JP 1 *
1-1 - POWER UNIT
1-6 - PRE OUT UNIT
2 1U-3601 CONNECT/VIDEO UNIT ASS'Y for EU,EC 1 *
2 1U-3601B CONNECT/VIDEO UNIT ASS'Y for E2,E2A 1 *
2 1U-3601F CONNECT/VIDEO UNIT ASS'Y for E1C,E1K 1 *
2 1U-3601E CONNECT/VIDEO UNIT ASS'Y for EUT 1 *
2 1U-3601D CONNECT/VIDEO UNIT ASS'Y for JP 1 *
2-1 - CONNECT UNIT
2-2 - FUNC.SEL UNIT
2-3 - S-VIDEO UNIT
2-4 - C-VIDEO UNIT
2-5 - VOL UNIT
2-6 - REMOTE I/O UNIT
2-8 - P.SW UNIT
2-9 - LED UNIT
2-10 - 232C UNIT
2-11 - H/P UNIT
3 1U-3596 CONTROL UNIT ASS'Y for EU,EC 1 *
3 1U-3596B CONTROL UNIT ASS'Y for E2,E2A 1 *
3 1U-3596F CONTROL UNIT ASS'Y for E1C,E1K 1 *
3 1U-3596E CONTROL UNIT ASS'Y for EUT 1 *
3 1U-3596D CONTROL UNIT ASS'Y for JP 1 *
3-1 - CONTROL UNIT
3-2 - TACT 38 UNIT
3-5 - COMP.3IN UNIT for EU,EC,E2,E2A,E1C,EUT,E1K
3-7 - VCONNECT UNIT
3 1U-3611 D VIDEO UNIT ASS'Y for JP 1 *
3-5 - D VIDEO UNIT for JP
4 1U-3472N AMP CONNECT UNIT ASS'Y for EU,EC 1 *
4 1U-3472Q AMP CONNECT UNIT ASS'Y for E2,E2A 1 *
4 1U-3472U AMP CONNECT UNIT ASS'Y for E1C,E1K 1 *
4 1U-3472S AMP CONNECT UNIT ASS'Y for EUT 1 *
4 1U-3472R AMP CONNECT UNIT ASS'Y for JP 1 *
4-1 - REGULATOR UNIT
4-2 - AMP CONNECT UNIT
4-3 - AC IN UNIT
4-4 - EXT.IN CONN.UNIT
4-5 - TU CONNECT UNIT
4-6 - AUDIO CONN. UNIT
5 1U-3595 AUDIO/DIGITAL UNIT ASS'Y for EU,EC 1 *
5 1U-3595B AUDIO/DIGITAL UNIT ASS'Y for E2,E2A 1 *
5 1U-3595F AUDIO/DIGITAL UNIT ASS'Y for E1C,E1K 1 *
5 1U-3595E AUDIO/DIGITAL UNIT ASS'Y for EUT 1 *
5 1U-3595D AUDIO/DIGITAL UNIT ASS'Y for JP 1 *
5-1 - DIGITAL UNIT
5-2 - AUDIO IN UNIT
5-3 - EXT.IN VR UNIT
5-4 - V.AUX UNIT
5-5 - MIC AMP UNIT
6 1U-3551 DSP ADI EX UNIT ASS'Y 1 *
Note : The symbols in the column “Remarks” indicate the following destinations.
EU : U.S.A. model E1C : China model
EC : Canada model EUT : Taiwan R.O.C. model
E2 : Europe model E1K : Korea model
E2A : Asia model JP : Japan model
