Denon AVC-X3800H User Manual

Connecting an external power amplifier
You can use this unit as a preamplifier by connecting an external power amplifier to the PRE OUT connectors. By adding a power amplifier to each
channel, the realness of the sound can be further enhanced.
Select the terminal to use and connect the device.
L
L
L
L
R R
RR
L
L
R
L
L
R
R R
L
L
R
R
CENTER
RL
FRONT
RL
AUDIO
SUB-
WOOFER
2
AUDIO
SUB-
WOOFER
1
AUDIO
RL
HEIGHT1 HEIGHT2
RL
SURROUND SURROUND
BACK
RL
SUB-
WOOFER
3
AUDIO
SUB-
WOOFER
4
AUDIO
Power amplifier
Subwoofer
(Primary)
Subwoofer Subwoofer Subwoofer
Contents
Connections Playback Settings Tips Appendix
42
Front panel Display Rear panel Remote Index

Denon AVC-X3800H Specifications

General

Channels	9.4
Power Output per Channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2ch driven)	105 W
Power Output per Channel (6 ohms, 1kHz, 0.7% 2ch driven)	135 W
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI Outputs	3
HDMI 2.1 Support	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Dolby Atmos	Yes
DTS:X	Yes
Auro-3D	Yes
IMAX Enhanced	Yes
Audyssey MultEQ XT32	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Network Connectivity	Ethernet, Wi-Fi
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
Amplifier Class	Class AB
Frequency Response	10 Hz - 100 kHz +1, -3 dB (Direct Mode)
Pre-Outs	11.4
Audio Inputs/Outputs	Analog, Digital
HDMI Inputs	6 + 1 (Front)
