Denon AVC-X3800H User Manual

Connecting a TV
Connect a TV to this unit so that the input video is output to the TV. You can also enjoy audio from the TV on this unit.
How to connect a TV depends on the connectors and functions equipped on the TV.
No
Yes
Is the TV equipped with an HDMI connector?
Yes No
Is the TV compatible with the ARC / eARC?
z
“Connection 1 : TV equipped with an HDMI
connector and compatible with the ARC /
eARC” (v p. 57)
“Connection 2 : TV equipped with an HDMI
connector and incompatible with the ARC /
eARC” (v p. 58)
You cannot connect the TV to this
unit.
z
What is ARC and eARC?
ARC (Audio Return Channel) sends audio back to this unit using the same HDMI cable that sends video from this unit to your TV.
This allows this unit to process the sound from your TV’s built-in tuner and apps.
TVs with eARC (Enhanced Audio Return Channel) port provide additional support for high bitrate multichannel audio (Dolby Atmos, Dolby TrueHD, DTS-HD and DTS:X).
Please refer to your TV Owner’s Manual for details about eARC support for your particular model.
NOTE
0
Use a TV with a 2 prong power plug for this unit. Do not connect a TV with a 3 prong power plug, as this may cause noise.
Contents Connections Playback Settings Tips Appendix
56
Front panel Display Rear panel Remote Index

Denon AVC-X3800H Specifications

General

Channels	9.4
Power Output per Channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2ch driven)	105 W
Power Output per Channel (6 ohms, 1kHz, 0.7% 2ch driven)	135 W
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI Outputs	3
HDMI 2.1 Support	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Dolby Atmos	Yes
DTS:X	Yes
Auro-3D	Yes
IMAX Enhanced	Yes
Audyssey MultEQ XT32	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Network Connectivity	Ethernet, Wi-Fi
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
Amplifier Class	Class AB
Frequency Response	10 Hz - 100 kHz +1, -3 dB (Direct Mode)
Pre-Outs	11.4
Audio Inputs/Outputs	Analog, Digital
HDMI Inputs	6 + 1 (Front)
