Connecting to a home network (LAN)
This unit can connect to a network using a wired LAN or wireless LAN.
You can connect this unit to your home network (LAN) to enable various
types of playback and operations as described below.
0
Playback of network audio such as Internet Radio and from your media
server(s)
0
Playback of streaming music services
0
Using the Apple AirPlay function
0
Operation on this unit via the network
0
Operation with the HEOS wireless multi-room sound system
0
Firmware Update
For connections to the Internet, contact an ISP (Internet Service
Provider) or a computer shop.
Wired LAN
To make connections via wired LAN, use a LAN cable to connect the
router to this unit as shown in the figure below.
Internet
Modem
PC
Router
To WAN side
To LAN port
To LAN port
NAS
(Network Attached
Storage)
LAN port /
Ethernet
connector
LAN port /
Ethernet
connector
Contents Connections Playback Settings Tips Appendix
66
Front panel Display Rear panel Remote Index

Denon AVC-X3800H Specifications

General

Channels	9.4
Power Output per Channel (8 ohms, 20Hz-20kHz, 0.08% THD, 2ch driven)	105 W
Power Output per Channel (6 ohms, 1kHz, 0.7% 2ch driven)	135 W
Speaker Impedance	4-16 ohms
Input Sensitivity/Impedance	200 mV / 47 kohms
Signal-to-Noise Ratio	102 dB
HDMI Outputs	3
HDMI 2.1 Support	Yes
8K/60Hz Pass-through	Yes
4K/120Hz Pass-through	Yes
HDR Support	HDR10, HDR10+, Dolby Vision, HLG
eARC Support	Yes
Dolby Atmos	Yes
DTS:X	Yes
Auro-3D	Yes
IMAX Enhanced	Yes
Audyssey MultEQ XT32	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
AirPlay 2	Yes
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Phono Input	Yes
Network Connectivity	Ethernet, Wi-Fi
Dimensions (W x H x D)	434 x 167 x 389 mm
Weight	12.5 kg
Amplifier Class	Class AB
Frequency Response	10 Hz - 100 kHz +1, -3 dB (Direct Mode)
Pre-Outs	11.4
Audio Inputs/Outputs	Analog, Digital
HDMI Inputs	6 + 1 (Front)
