Denon AVC-X6500H User Manual

Connecting 11.1-channel speakers
This system, which is based on a 5.1-channel system, plays back up to 11.1-channels at the same time.
o
Example connection when using two sets of ceiling speakers
.
C
FL FR
SBL
SBR
SW
SL SR
TRL TRR
TFL TFR
0
Set “Height” - “Height Sp” to “4ch” in the menu when connecting in this
configuration. (v
p. 214)
.
ASSIGNABLE ASSIGNABLE ASSIGNABLE
SPEAKERS
CENTER SURROUND SURROUNDBACK SURROUNDFRONT SURROUNDBACK FRONT
SW
SBR SBLFR FL C SR SL
TFR TFL
HEIGHT 1
z
TRR TRL
HEIGHT 2
z
z
You can change the combination of the HEIGHT1 and HEIGHT2 channels in the
settings. (v p. 63)
Contents
Connections Playback Settings Tips Appendix
59
Front panel Display Rear panel Remote Index
