AVR-3801
SPECIFICATIONS
!!
!!
! AUDIO SECTION
""
""
" Power Amplifier
Rated output: Front: 105W + 105W (8Ω/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
150W + 150W (6Ω/ohms, 1kHz with 0.7% T.H.D.)
180W + 180W (6Ω/ohms, EIAJ)
Center: 105W (8Ω/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
150W (6Ω/ohms, 1kHz with 0.7% T.H.D.)
180W + 180W (6Ω/ohms, EIAJ)
Surround: 105W + 105W (8Ω/ohms, 20Hz ~ 20kHz with 0.05% T.H.D.)
150W + 150W (6Ω/ohms, 1kHz with 0.7% T.H.D.)
180W + 180W (6Ω/ohms, EIAJ)
Surround Back: 105W + 105W (8Ω/ohms, 20 Hz ~ 20kHz with 0.05% T.H.D.)
150W + 150W (6Ω/ohms, 1kHz with 0.7% T.H.D.)
180W + 180W (6Ω/ohms, EIAJ)
Dynamic power: 140W × 2ch (8Ω/ohms)
210W × 2ch (4Ω/ohms)
240W × 2ch (2Ω/ohms)
Output terminals: Front, Center, Surr. Back/Multi Zone: 6 ~ 16Ω/ohms
Surround: A or B 6 ~ 16Ω/ohms
A + B 8 ~ 16Ω/ohms
""
""
" Analog
Input sensitivity/input impedance: 200mV/47kΩ/kohms
Frequency response: 10Hz ~ 100kHz: +0, −3dB (DIRECT model)
S/N: 102dB (DIRECT mode)
Distortion: 0.005% (20Hz ~ 20kHz) (DIRECT mode)
Rated output: 1.2V
""
""
" Digital
D/A output: Rated output 2V (at 0dB playback)
Total harmonic distortion 0.008% (1 kHz, at 0 dB)
S/N ratio 102dB
Dynamic range 96dB
Digital input: Format Digital audio interface
""
""
" Phono equalizer (PHONO input
REC OUT)
Input sensitivity: 2.5mV
RIAA deviation: ±1dB (20Hz to 20kHz)
Signal-to-noise ratio: 74dB (A weighting, with 5mV input)
Rated output/Maximum output: 150mV/8V
Distortion factor: 0.03% (1kHz, 3V)
!!
!!
! VIDEO SECTION
""
""
" Standard video jacks
Input/output level and impedance: 1Vp-p, 75Ω/ohms
Frequency response: 5Hz ~ 10MHz +0, −3dB
""
""
" S-video jacks
Input/output level and impedance: Y (brightness) signal 1Vp-p, 75Ω/ohms
C (color) signal 0.286Vp-p, 75Ω/ohms
Frequency response: 5Hz ~ 10MHz +0, −3dB
""
""
" Color component video jacks
Input/output level and impedance: Y (brightness) signal 1Vp-p, 75Ω/ohms
CB (blue) signal 0.7Vp-p, 75Ω/ohms
CR (red) signal 0.7Vp-p, 75Ω/ohms
Frequency response: 5Hz ~27MHz +0, −3dB
!!
!!
! TUNER SECTION
[FM] (note: µV at 75Ω/ohms, 0dBf=1 × 10
-15
W) [AM]
Receiving Range: 87.50MHz ~ 107.90MHz 520kHz ~ 1710kHz
(for North America and multiple voltage models) (for North America and Multiple voltage models)
87.50MHz ~ 108.00MHz 522kHz ~ 1611kHz
(for Europe, China, Hong Kong, Taiwan R.O.C. and Multiple voltage models) (for Europe, China, Hong Kong, Taiwan R.O.C. and multiple voltage models)
Usable Sensitivity: 1.0µV (11.2dBf) 18µV
50dB Quieting Sensitivity: MONO: 1.6µV (15.3dBf)
STEREO: 23µV (38.5dBf)
S/N (IHF-A): MONO: 80dB
STEREO: 75dB
Total Harmonic Distortion (at 1kHz): MONO: 0.15%
STEREO: 0.3%
!!
!!
! GENERAL
Power supply: AC120V, 60Hz (for North America and Taiwan R.O.C. models)
AC230V, 50Hz (for Europe model)
AC220V, 50Hz (for China model)
AC115V/230V, 50/60Hz (for Hong Kong and Multiple voltage models)
Power consumption: 7.0A (for North America model)
400W (for Europe, China, Hong Kong and Multiple voltage models)
360W (for Taiwan R.O.C. model)
2.0W Max (Standby)
Maximum external dimensions: 434 (W) × 171 (H) × 416 (D)mm (17-3/32″ × 6-11/32″ × 16-3/8″)
Weight: 17.0kg (37 lbs 8 oz)
!!
!!
! REMOTE CONTROL UNIT (RC-883: for North America, China, Hong Kong, Taiwan R.O.C. and Multiple voltage models)
(RC-884: for Europe model)
Batteries: R6P/AA Type (three batteries)
External dimensions: 61 (W) × 230 (H) × 34 (D)mm (2-13/32″ × 9-1/16″ × 1-11/32″)
Weight: 200g (Approx. 7 oz) (including batteries)
* For purposes of improvement, specifications and design are subject to change without notice.
SAFETY PRECAUTIONS
The following check should be performed for the continued protection of the customer and service technician.
LEAKAGE CURRENT CHECK
Before returning the unit to the customer, make sure you make either (1) a leakage current check or (2) a line to chassis
resistance check. If the leakage current exceeds 0.5 milliamps, or if the resistance from chassis to either side of the
power cord is less than 460 kohms, the unit is defective.
