Denon AVR-A1H User Manual

Connecting 7.1-channel speakers
o
Example connections when using surround back speakers
This 7.1-channel surround system is the same as a basic 5.1-channel system but with surround back speakers.
.
FL
SW C
SL
FR
SR
SBRSBL
0
Set “Floor” - “Layout” to “5ch & SB” in the menu when connecting in this
configuration. (v p. 235)
.
1 CBL/SAT
PHONO
2 DVD 1 CBL/SAT
2 CD 1
TV
AUDIO
6 CD
2 DVD
12
3 Blu-ray
5 MEDIA PLAYER
4 GAME
RS-232C
7.1CH IN
REMOTE CONTROL TRIGGER OUT
PRE OUT
COAXIAL OPTICAL
STRAIGHT CABLE
I
R
DC12V 150mA MAX.
ZONE2 ZONE3
FRONT
FRONT
SURROUND CENTER SUBWOOFER
SURROUND BACK
CENTER
SURROUND BACK
SURROUND
HEIGHT2 HEIGHT4/FRONT WIDE
1
AUDIO
(ASSIGNABLE)
AUDIO
DIGITAL AUDIO
(ASSIGNABLE)
2
SUBWOOFER
HEIGHT1
HEIGHT3
ASSIGNABLE
SPEAKERS
FRONT FRONT
CENTER
SURROUND SURROUND
SURROUND BACK SURROUND BACK
ASSIGNABLE
ASSIGNABLE AS SIGNABLE
ASSIGNABLE
HEIGHT4/FRONT WIDE HEIGHT3 HEIGHT3
HEIGHT1 HEIGHT1 HEIGHT2 HEIGHT2
HEIGHT4/FRONT WIDE
SBR SBL
SW
FR FL C SR SL
0
When using a single surround back speaker, connect it to the SURROUND BACK
L terminal.
Contents Connections Playback Settings Tips Appendix
49
Front panel Display Rear panel Remote Index

Denon AVR-A1H Specifications

General

Channels	15.4
Power Output	150 W per channel (8 ohms, 20 Hz - 20 kHz, 0.05% THD)
HDMI Inputs	7
HDMI Outputs	3
Dolby Atmos	Yes
DTS:X	Yes
IMAX Enhanced	Yes
Auro-3D	Yes
HEOS Built-in	Yes
Wi-Fi	Yes
Bluetooth	Yes
Weight	70.5 lbs
HDCP Support	HDCP 2.3
HDR Compatibility	HDR10, HDR10+, Dolby Vision, HLG
Wireless Audio	AirPlay 2, Bluetooth, HEOS
Phono Input	Yes
Frequency Response	10 Hz - 100 kHz
Voice Control	Amazon Alexa, Google Assistant, Apple Siri
Inputs	7 HDMI, 1 phono
Outputs	3 HDMI
Supported Audio Formats	MP3, WAV, FLAC, ALAC, DSD
Total Harmonic Distortion	0.05% (20 Hz - 20 kHz)
