DSW-3.1
PARTS LIST OF P.W.B. UNIT ASS'Y
＊本表に記載されている部品は、補修用部品のため製品に使用してい
る部品とは一部、形状、寸法などが異なる場合があります。
Ref. No. Part No. Part Name Remarks Q'ty New
SEMICONDUCTORS GROUP
IC401 9H30001047 ICNJM4558MTE1 070146
*
IC501 9H30001047 ICNJM4558MTE1 070146
*
IC502 9H30001047 ICNJM4558MTE1 070146
*
IC503 9H30001047 ICNJM4558MTE1 070146
*
IC504 9H30001047 ICNJM4558MTE1 070146
*
IC505 9H30001047 ICNJM4558MTE1 070146
*
IC601 9H30001047 ICNJM4558MTE1 070146
*
IC602 9H30001068 ICSTK402-250 380017
*
D401 9H30001045 D1SS355TE-17 069444
*
D402 9H30001045 D1SS355TE-17 069444
*
D403 9H30001045 D1SS355TE-17 069444
*
D404 9H30001045 D1SS355TE-17 069444
*
D405 9H30001045 D1SS355TE-17 069444
*
D406 9H30001045 D1SS355TE-17 069444
*
D407 9H30001045 D1SS355TE-17 069444
*
D501 9H30001045 D1SS355TE-17 069444
*
D502 9H30001045 D1SS355TE-17 069444
*
D503 9H30001045 D1SS355TE-17 069444
*
D504 9H30001045 D1SS355TE-17 069444
*
D505 9H30001045 D1SS355TE-17 069444
*
D506 9H30001045 D1SS355TE-17 069444
*
D507 9H30001045 D1SS355TE-17 069444
*
D508 9H30001045 D1SS355TE-17 069444
*
D601 9H30001045 D1SS355TE-17 069444
*
D602 9H30001045 D1SS355TE-17 069444
*
D603 9H30001045 D1SS355TE-17 069444
*
D604 9H30001045 D1SS355TE-17 069444
*
D701 9H30001045 D1SS355TE-17 069444
*
D702 9H30001045 D1SS355TE-17 069444
*
D703 9H30001045 D1SS355TE-17 069444
*
D704 9H30001045 D1SS355TE-17 069444
*
D801 9H30000876 DRBV602 069599
*
D802 9H30001056 ZDUDZ15BTE-17 084686
*
D803 9H30001056 ZDUDZ15BTE-17 084686
*
D804 9H30001046 D1SR139-400T-32 069536
*
D805 9H30001046 D1SR139-400T-32 069536
*
D806 9H30001046 D1SR139-400T-32 069536
*
D807 9H30001046 D1SR139-400T-32 069536
*
D809 9H30001042 ZDUDZ12BTE-17 069032
*
D810 9H30001042 ZDUDZ12BTE-17 069032
*
D811 9H30001045 D1SS355TE-17 069444
*
LD401 9H30000875 LEDBL-BEG204RED/GREEN 084696
*
Q401 9H30001035 TR2SA1037AKQRST146 068590
*
Q402 9H30001044 TRDTC124EKAT146 069317
*
Q403 9H30001043 TRDTA124EKAT146 069264
*
Q404 9H30001043 TRDTA124EKAT146 069264
*
Q405 9H30001040 TR2SC2412KQRST146 068775
*
Q406 9H30001040 TR2SC2412KQRST146 068775
*
Q407 9H30001040 TR2SC2412KQRST146 068775
*
Q408 9H30001035 TR2SA1037AKQRST146 068590
*
