DeWalt DCN650 User Manual

ENGLISH
1
English (original instructions)
Definitions: Safety Alert Symbols and Words
This instruction manual uses the following safety alert symbols and words to alert you to hazardous situations and your risk
of personal injury or property damage.

DANGER: Indicates an imminently hazardous situation which, if not avoided, will result in death or seriousinjury.

WARNING: Indicates a potentially hazardous situation which, if not avoided, could result in death or seriousinjury.

CAUTION: Indicates a potentially hazardous situation which, if not avoided, may result in minor or moderateinjury.

(Used without word) Indicates a safety related message.
NOTICE: Indicates a practice not related to personal injury which, if not avoided, may result in propertydamage.

WARNING! Read all safety warnings and all
instructions. Failure to follow the warnings and
instructions may result in electric shock, fire and/or
seriousinjury.
WARNING: To reduce the risk of injury, read the
instructionmanual.
If you have any questions or comments about this or
any
DeWALT
tool, call us toll free at:
1-800-4-
DeWALT
(1-800-433-9258).
1
Trigger
2
Trigger lock-off
3
Depth adjustment wheel
4
Headlights/Low battery/Stall indicator
5
Jam clearing latch
6
Contact trip
7
Magazine
8
Pusher
9
Bump/sequential selector switch
10
Belt hook
11
No-mar pad
12
No-mar pad storage
13
Stall release lever
14
Battery
15
Nail depth indicator
16
Battery release button
Fig. A
15
3
12
47
1410
13
5
8
6
11
1 2
16
9

DeWalt DCN650 Specifications

General

Brand	DeWalt
Model	DCN650
Category	Nail Gun
Language	English
