DeWalt DWS780 User Manual

English
7
FIG. 4
KERF
PLATE
MOTOR
HOUSING
RAIL SET
SCREW
ADJUSTMENT
RAIL LOCK
KNOB
MOTOR
ENDCAP
BEVEL SCALE
LOCK DOWN
PIN
MITER
LATCH
BUTTON
TABLE
MITER LATCH
OVERRIDE
MITER
SCALE
MITER LOCK
HANDLE
FENCE
ADJUSTMENT
KNOB
(ONE EACH SIDE)
BENCH MOUNTING HOLES
LIFTING
HANDLE
DUST DUCT
INLET
FENCE
HAND
INDENTATION
RAILS
OPERATING
HANDLE
LOWER
GUARD
BELT COVER
BEVEL LOCK
KNOB
TRIGGER
SWITCH
0° BEVEL
STOP
WING NUT
DEPTH
ADJUSTMENT
SCREW
DEPTH STOP
FENCE
ADJUSTMENT
KNOB
(one each side)
BLADE WRENCH
XPS
TM
ON/OFF
SWITCH
BASE
FIG. 5
MITER
POINTER
MITER
SCALE
SCREW
(4 places)
MITER POINTER SCREW
MITER
LATCH
BUTTON
MITER LOCK
HANDLE
MITER LATCH
OVERRIDE

DeWalt DWS780 Specifications

General

Input power	1675 W
Power source	AC
Blade bore	30 mm
Blade diameter	305 mm
Saw blade included	Yes
Idle speed (max)	3800 RPM
Cutting capacity 45° miter	212 x 76 mm

Weight and Dimensions

Depth	470 mm
Height	396 mm
Weight	24800 g
