users ‘ instructions
B1600 - B2200
17
GB
Installation instructions 2
Fix the cooling unit to the brackets using
the 4 screws provided.
Mount the fi lters in the order shown in
fi gure.
Mount the fi lters covers.
THICKNESS OF THE ROOF THICKNESS OF THE GASKET
to 30 mm 10 mm
from 30 to 35 mm 15 mm
from 35 to 40 mm 20 mm
from 40 to 45 mm 25 mm
from 45 to 50 mm 30 mm
from 50 to 55 mm 35 mm
from 55 to 60 mm 40 mm
from 60 to 65 mm 45 mm
from 65 to 70 mm 50 mm
from 70 to 75 mm 55 mm
from 75 to 80 mm 60 mm
