Domino G20I Operator's Quick Reference Guide

G20i Operator’s Quick Reference Guide
START PRINTING
To start printing using the wireless USB keyboard:
(1) From the Main Menu, use the arrow keys to highlight
Operation.
(2) Press the Enter button.
(3) Press the Enter button to select Start.
Main menu
Message
Operation
Settings
Operation
Start
Purge
Connect PC
STOP PRINTING
To stop printing using the wireless USB keyboard:
(1) From the Main Menu, use the arrow keys to highlight
Operation.
(2) Press the Enter button.
(3) Press the Enter button to select Stop.
Main menu
Message
Operation
Settings
Operation
Stop
Purge
Connect PC
CREATE A MESSAGE
To create a message using the wireless USB keyboard:
(1) From the Main Menu, use the arrow keys to highlight
Message and press the Enter button.
(2) Press the Enter button to select Create New.
(3) Use the arrow keys to highlight Normal font or
Uppercase font and press the Enter button.
Main menu
Message
Create New
Open
Information
Message
Normal font
Uppercase font
(4) Highlight the required Font size and number of lines of
text, then press the Enter button.
(5) Use the keyboard to input a text item into the message,
or press the Insert button to enter other data types.
(6) Press the ESC key when finished.
(7) Select Save to save the message to internal memory, or
select No to discard the message.
Message
Font
12.7mm
Lines
1
5.92mm
2
2.54mm
4
1.69mm
6
3.89mm
3
Edit message
TEXT
(3) Set Active to Enable.
(4) Edit the printer’s Name and Pin, press Enter when
complete.
String
Purge
Print side
Sensor
Direction
Print Mode
Unit
Bluetooth
Settings
Active:
Name:
Pin:
Enable
G20i
1234
String
Purge
Print side
Sensor
Direction
Print Mode
Unit
Bluetooth
Settings
Active:
Name:
Pin:
Enable
Printer1
1331
BLUETOOTH SETUP
To control the printer from an Android device via Bluetooth:
(1) From the Main Menu, use the arrow keys to highlight
Settings and press the Enter button.
(2) Highlight Bluetooth and press the Enter button.
Main menu
Message
Operation
Settings
String
Purge
Print side
Sensor
Direction
Print Mode
Unit
Bluetooth
Settings
(5) Install the Domino G20i application on the Android
device.
(6) Turn on Bluetooth on the Android device.
(7) Open the G20i printer application.
(8) Select Printers.
(9) Select Search.
(10) Select the name of the printer when it appears in the
Printers list.
(11) Select Connect.
ADDITIONAL DOCUMENTATION
• Documentation in your local language is available at:
www.DominoCaseCoding.com
• 文档下载地址 :
www.DominoCaseCoding.com
• 繁體中文手冊 :
www.DominoCaseCoding.com
• Tài liệu với ngôn ngữ của bạn có sẵn tại:
www.DominoCaseCoding.com
• Dokumen dalam bahasa lokal tersedia di:
www.DominoCaseCoding.com
• / :
www.DominoCaseCoding.com
• 日本語マニュアルはここから入手できます :
www.DominoCaseCoding.com
© Domino Printing Sciences plc 2016
EPT024620 Issue 1 June 2016

Domino G20I Specifications

General

Brand	Domino
Model	G20I
Category	Printer
Language	English
