Instructions for use – Infinity Acute Care System – Monitoring Applications VG6.n 413
External devices – MEDIBUS.X devices
The Show all pages
The Show all page displays the values and units of
measure of the currently monitored parameters in
one screen. The following two Show all pages are
available:
– Under the Anesthesia workstation tab
The anesthesia Show all page displays the
following data:
– Current ventilator measurements
– Current gas measurements
– Current consumption
– Units of measure
The ventilator Show all page displays the following
data:
– Current ventilator measurements
– Units of measure
The ventilator Show all page can be configured
(see page 413).
To access the Show all pages
You can access the Show all page in the
Ventilator or the Anesthesia workstation tabs.
Which tab is displayed depends on whether a
ventilator or an anesthesia workstation is
connected.
1 Select the Sensor parameters... button on the
main menu bar.
2 Select Ventilator or Anesthesia workstation
> Show all.
Configuring the ventilator Show all page
You can configure the parameter display of the
ventilator Show all page and adapt it to the
parameter set of the connected device.
To configure the ventilator Show all page
1 Select the Sensor parameters... button on the
main menu bar.
Select Ventilator > Configure show all. A page
with twenty-six buttons appears.
NOTE
Depending on which devices are connected to the
Cockpit, two Ventilator tabs may be displayed.
The MEDIBUS.X Ventilator tab is the one that
has the message Medibus.X ventilator devices
displayed as a header on the various pages.
NOTE
If a Scio module is connected, the values in the
Current measurements gases section come
from the Scio module, regardless of which MEDI-
BUS.X device is connected.
NOTE
Depending on which devices are connected to the
Cockpit, two Ventilator tabs may be displayed.
The MEDIBUS.X Ventilator tab is the one that
has the message Medibus.X ventilator devices
displayed as a header on the various pages.
NOTE
Depending on which devices are connected to the
Cockpit, two Ventilator tabs may be displayed.
The MEDIBUS.X Ventilator tab is the one that
has the message Medibus.X ventilator devices
displayed as a header on the various pages.
