Ducati 999 User Manual

76
E
10 m
9
10
x
x
fig. 73
Beam setting (fig. 73)
When checking the beam setting, put the motorcycle
upright. Tyres should be inflated at the correct pressure
and one person should be sitting astride the motorcycle,
keeping it at right angles to its longitudinal axis. Place the
motorcycle opposite a wall or a screen, 10 meters apart
from it, then draw a horizontal line dictated by headlamp
center and a vertical one in line with the longitudinal axis
of motorcycle.
If possible, perform this check in dim light.
Switch on the low beam. The height of the light spot
(measured at the upper limit between dark and lighted-up
area) should not exceed 9/10th of the height from ground
of headlamp center.
Note
The procedure described here is in compliance with
the “Italian Standard” establishing the maximum height
of the light beam. Owners in other countries will adapt
said procedure to the provisions in force in their
countries.

Ducati 999 Specifications

General

Compression Ratio	11.4:1
Transmission	6-speed
Fuel Tank Capacity	15.5 l (4.1 US gal)
Rear Suspension	Progressive linkage with fully adjustable Showa monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Rear Brakes	240 mm disc, 2-piston caliper
Tire Front	120/70 ZR 17
Tire Rear	190/50 ZR 17
Engine Type	L-Twin cylinder, 4 valves per cylinder Desmodromic
Bore x Stroke	100 mm x 63.5 mm
Power	104 kW (141 hp) @ 9750 rpm
Torque	110 Nm (81.4 lb-ft) @ 8000 rpm
Front Suspension	Showa 43 mm upside-down fork, fully adjustable
