Ducati 999S User Manual

8
5
6
9
3
7
4
2
1
10
10
11
E
Instrument panel (fig. 4)
1) LCD (see page 12).
2) Engine revolution meter (rpm)
Indicates engine rpm.
3) Neutral light N (green).
Comes on when gearbox is in neutral.
4) Low fuel light (yellow).
Comes on when there are about 3 liters fuel left in the
tank.
5) Turn indicator light (green).
Comes on and flashes when a turn indicator is on.
6) Engine oil pressure light (red).
Comes on when engine oil pressure is too low. It comes
on when the ignition is switched to ON and normally
goes out a few seconds after engine starts.
It may shortly come on when the engine is hot, however,
it should go out as the engine revs up.
Important
If this light (6) stays on, stop the engine or it may
suffer severe damage.
7) High beam light (blue).
Comes on when high beam is on.
fig. 4

Ducati 999S Specifications

General

Displacement	998 cc
Transmission	6-speed
Rear Brakes	Single 240 mm disc, 2-piston caliper
Bore x Stroke	100 mm x 63.5 mm
Frame	Tubular steel trellis
Engine Type	L-twin, 4 valves per cylinder, Desmodromic
Front Suspension	Showa 43 mm fully adjustable upside-down fork
Rear Suspension	Fully adjustable Ohlins monoshock
Front Brakes	2 x 320 mm discs, 4-piston calipers
Fuel Capacity	15.5 liters
Fuel Injection	Marelli electronic fuel injection
Exhaust	2-1-2 system with catalytic converter
Torque	106 Nm @ 8, 000 rpm
