Attention
If the rear sprocket needs replacing, contact a
Ducati Dealer or authorized Service Center.
Incorrect replacement of this component could
seriously endanger rider and passenger safety and
cause irreparable damage to the motorcycle.
Frame
Steel tube trellis frame.
Die-cast aluminum rear subframe.
Steering head angle: 25.5°.
Wheels
Front
10-spoke, light-alloy rims.
Size: MT3.50x17"
Rear
10-spoke, light-alloy rims.
Size: MT5.50x17"
Both wheel shafts can be removed.
Tires
Front
Tubeless, radial tire.
Size: 120/70-ZR17
Rear
Tubeless, radial tire.
Size: 180/55-ZR17
Suspensions
Front
Hydraulic upside-down fork
Stanchion diameter:
1.69 in (43 mm).
Wheel travel: 6.69 in (170 mm).
Rear
Progressive. The shock absorber is adjustable for
rebound and spring preload. At the bottom pivot point
it is connected to a die-cast aluminum single-sided
swingarm. The whole system gives the bike excellent
stability.
Shock absorber stroke 2.42 in (61.5 mm).
Rear wheel travel: 5.90 in (150 mm).
Exhaust system
Single stainless steel absorption type muffler.
Catalytic converter built into the silencer with two
Lambda sensors on the exhaust pipes at the head
output.
215
