Eaton 33 Parts & Repair Information

9
Parts List – Series 2 Variable Displacement Pump
Item Part No. Qty. Description
41 A ◊ A/R Bearing Shim (54,4 - 63,7 - 75,4 cm
3
/rev) (see Shim kit 990715-000 page 26)
◊ A/R Bearing Shim (89,2 - 105,5 cm
3
/rev) (see Shim kit 990388-000 page 26)
42A43A 108295-000 1 Bearing Cup/ Bearing Cone S/A (54,4 - 63,7 - 75,4 cm
3
/rev)
42A43A 990386-000 1 Bearing Cup/ Bearing Cone S/A (89,2 - 105,5 cm
3
/rev)
44 B ♦ 2 Swash Bearing (54,4 - 63,7 - 75,4 cm
3
/rev) (see assembly parts list on page 11)
♦ 2 Swash Bearing (89,2 - 105,5 cm
3
/rev) (see assembly parts list on page 11)
45 B 108331 2 Race Pin
46 B 108823 2 Clocking Link (54,4 - 63,7 - 75,4 cm
3
/rev)
108973 2 Clocking Link (89,2 - 105,5 cm
3
/rev)
47 B 108152 1 Slide Block (54,4 - 63,7 - 75,4 cm
3
/rev)
108349 1 Slide Block (89,2 - 105,5 cm
3
/rev)
48 C ◊ 1 Low Pressure Relief Valve Plug (see LPRV Kit 9900713-000 page 26)
49 C ◊ 1 O-Ring (see gasket kit 990710-000 page 27)
53 B 108214 2 Hold Down Spring
54 B 16048-480 2 Hold Down Washer
55 A 107582 2 Hollow Dowel (54,4 - 63,7 - 75,4 cm
3
/rev)
108369 2 Hollow Dowel (89,2 - 105,5 cm
3
/rev)
56 A/B 98202 3 Dowel
57 A ◊ 4 Static Face Seal (see gasket kit 990710-000 page 27)
59 A ◊ 2 O-Ring (located between end cover and housing see page 27)
60 A ◊ 2 Back-up Ring (located between end cover and housing see page 27)
61 C 25083-01 1 O-Ring Plug
62 C 107887 1 O-Ring Plug Soc HD
63 A 25706-006 2 O-Ring Plug
64 A 25090-010 1 O-Ring Plug
65 A 25090-004 3 O-Ring Plug
66 A/C 25083-004 12 O-Ring Plug (not all positions shown in views)
67 A/C 25083-002 3 O-Ring Plug (used with IPOR if option is installed)
68 96559 1 Shipping Strap (54,4 - 63,7 - 75,4 cm
3
/rev) (not shown in view)
69 101822 1 Shipping Strap (89,2 - 105,5 cm
3
/rev) (not shown in view)
76 A 108840-xxx 2 Relief Valve, POR (Optional)
xxx = last 3 digits indicate pressure setting i.e. -300 = 3000 psi
78 A 109183-xxx 1 Relief Valve and or Check Valve (B Port)
xxx =last 3 digits indicate pressure setting i.e. -450 = 4500 psi
79 A 109183-xxx 1 Relief Valve and or Check Valve (A Port)
xxx = last 3 digits indicate pressure setting i.e. -650 = 6500 psi
80 ♦ 1 Control Valve Orfice
81 ♦ 1 Control Valve Orfice
82 ♦ 1 Control Valve Supply Orfic,
83 95653-012 2 Soc Pipe Plug .125-27 NPTF (inside charge pump inlet port)
84 95653-006 2 Soc Pipe Plug .062-27 NPTF(inside charge pump inlet port)
85 C ◊ 1 Magnetic Speed Sensor (see Speed Sensor Kit page 21)
108307 1 Plug (Optional)
86 C 16160-125 1 Retaining Ring (Optional)
Legend ♦ Refer to specific item assembly parts list. A/R – As Required
◊ Parts included in Kit. (Refer to specific Parts Kit list.)
