Page 10
614-09406-00 - 3S ANZ_EN
5. Operation
Battery change:
OFF
A
C
E
F
D
B
Warning: take care not to reverse the polarity + (red) and - (black) when connecting the batteries as this will
destroy the device.

Table of Contents

Questions and Answers:

Question and Answer IconNeed help?

Do you have a question about the Eaton 3S and is the answer not in the manual?

Eaton 3S Specifications

General IconGeneral
Surge ProtectionYes
Humidity0-95% non-condensing
Power Rating700VA / 420W
Output Voltage230 V
Frequency50-60 Hz
Input ConnectionsIEC 320 C14
Battery TypeSealed Lead-Acid
Communication PortsUSB
Operating Temperature0 to +40°C
Storage Temperature-15 to +45°C
Data line protectionData Line Protection (Internet/Tel/Fax)
