Page 41
5-6kVA EU_EN
ENGLISH
9. Specifications
Table 6. Electrical output
All models Normal mode Battery mode
Voltage regulation ±1% ±1%
Efficiency > 98% (High Efficiency mode)
> 93%
> 91%
Frequency regulation Sync with line ±5% of nominal line
frequency (outside this range: ±0.5%
of auto-selected nominal frequency)
±0.5% of auto-selected nominal
frequency
Nominal output 200/208/220/230/240V (voltage configurable)
5000/6000VA 4500/5400W
Frequency 50 or 60Hz, autosensing or configurable as a frequency converter
Output overload 100-102% : no alarm
102-110% : load transfers to Bypass mode after 2 minutes
110-125% : load transfers to Bypass mode after 1 minute
125-150% : load transfers to Bypass mode after 10s
> 150% : load transfers to Bypass mode after 500ms
Output overload
(Bypass mode)
100-125% : no alarm
125-150% : UPS shuts down after 1 minute
> 150% : UPS shuts down after 1s
Voltage waveform Sinewave
Harmonic distortion < 2% THDV on linear load
< 5% THDV on non-linear load
Transfer time Online mode: 0 ms (no break)
High Efficiency mode: 10ms maximum (due to loss of utility)
Power factor 0.9
Load crest ratio 3 to 1
Table 7. Electrical output connections
Model Output connection Output cable
9SX5KiRT Hardwired
(2) IEC16A
(4) IEC10A group 1
(4) IEC10A group 2
Not provided
9PX5Ki
9SX6KiRT
9PX6Ki
Table 8. Environmental and safety
EMC certifications IEC/EN 62040-1: 2008
IEC/EN 62040-2: 2006 Cat. C2
IEC/EN 62040-3: 2011
IEC 60950-1
UL 1778 4
th
CSA 22.2
EMC (Emissions)* CISPR22 Class A
AS/NZS 22 Class A
IEC 61000-3-2 (-3-12)
IEC 61000-3-3 (-3-11)
FCC part 15 Class A
EMC (Immunity) IEC 61000-2-2
IEC 61000-4-2, Level 3
IEC 61000-4-3, Level 3
IEC 61000-4-4, Level 4 (also on signal ports)
IEC 61000-4-5, Level 4, Criteria B
IEC 61000-4-6, Level 3
IEC 61000-4-8, Level 4
IEC 61000-4-11
* for output cable < 10m.
